PREFACE ABOUT THIS MANUAL

This User’s Manual is provided for users seeking advanced technical information, includ- ing connection, programming, maintenance and specifications. Other publications asso- ciated with this product can be downloaded free of charge from the website listed on the back cover of this manual.

Manual Conventions

The following conventions are used in this document:

The symbols listed below are used in this manual to notify the reader of key issues or procedures that must be observed when using the reader:

NOTE: Notes contain information necessary for properly diagnosing, repairing and operating the reader.

CAUTION: This symbol advises you of actions that could damage equipment or property.

WARNING: This symbol advises you of actions that could result in harm or injury to the person performing the task.

TECHNICAL SUPPORT

Support Through the Website

Datalogic provides several services as well as technical support through its website. Log on to (www.datalogic.com).

For quick access, from the home page click on the search icon , and type in the name of the product you’re looking for. This allows you access to download Data Sheets, Manu- als, Software & Utilities, and Drawings.

Hover over the Support & Service menu for access to Services and Technical Support.

Reseller Technical Support

An excellent source for technical assistance and information is an authorized Datalogic reseller. A reseller is acquainted with specific types of businesses, application software, and computer systems and can provide individualized assistance.

CHAPTER 1 INTRODUCTION

NOTE: The images shown in this user manual are for illustration purposes only and may not be an exact representation of the software.

DL.CODE software is a User Interface client application that provides reading device con- figuration for Stand Alone, and Master/Slave configurations. It is installed in and runs on Windows-based PCs (usually laptops), and connection takes place through an Ethernet TCP/IP interface.

It also provides visual monitoring of images that can be stored in an Image Database either locally on the device or to the local or a remote PC.

DL.CODE provides PackTrack Calibration for omnidirectional reading and tracking sta- tions used in Logistics applications.

DL.CODE offers statistic and diagnostic information at reading station level whether the station is made up of a single reader or several readers connected in a Master Slave con- figuration.

Figure 1 - Main Window Areas

MAIN FEATURES

A summary of the DL.CODE main features is listed below:

• Simultaneous Device Monitoring from different remote PCs

• 3 different User access levels

• User and Session Language configuration in real time

• System configuration

• Dynamic content and automatic page update

CONFIGURATION AND MONITORING SESSIONS

Device configuration can be performed using DL.CODE running on a remote PC through a single session. Multiple instances of DL.CODE cannot be run on a PC and once a device is connected for configuration it cannot be accessed by another PC running DL.CODE.

However the Monitoring feature can be accessed simultaneously by several PCs running DL.CODE.

SIMULATORS

DL.CODE has different device prototypes which can be loaded as Offline devices. This allows offline configurations to be prepared and loaded to a device at a later time.

NOTE: Creating and saving offline configuration (.dlcfg) files and then loading them onto physical devices can be done but the following precautions should be followed:

- Due to differences in image sensors, internal memory, etc., it is strongly sug- gested to use the same family product as the device to be configured.

- The following parameter groups may need to be adjusted: Manual Setup Image Settings, Reading Phase, Output Setup.

- Manual Setup Code Settings, Good Read, and Data Formatting will be maintained.

DEVICE CONFIGURATION

To load a Simulator, Click on the Offline Devices tab at the bottom of the Device List Area to open the list of available simulators.

All of the simulators are offline by default. To select a reader click its Simulator Power button icon.

Now you can double-click or drag the simulator into the Selected Device Information Area and begin a new configuration. See Chapter 3, .

DEVICE CONFIGURATION

DL.CODE is designed to simplify standard configuration by grouping the basic functions into five major parameter groups: Image and Code Settings, which manage decoding options, Reading Phase, Good Read Setup, which manage the operating mode, Data Formatting and Output Setup, for the output.

Figure 2 - DL.CODE Configuration Groups

Decoding Settings Operating Mode Output

Image and Code Settings:

Automatic Setup: this is a new feature that provides a one-step process for automati- cally setting the photometry for image acquisition (Image Setting) and the code symbol- ogy selection. This is particularly useful for DPM applications and requires no calibration. See "Automatic Setup Configuration" starting on page 20.

Manual Setup: this group completely manages:

• Image Setting parameters, including Image Auto Setup for photometry, multiple Image Settings, Focus Autolearn for liquid lens models, a Focus Calibration tool with oscilloscope for manual focusing and a PPI acquisition tool for calibration.

• General Settings including Processing Time and Code Grading parameter man- agement.

• Code Symbology selection and configuration including Code Filtering parameters and a Code Localization tool. It also contains the Code Autolearn routine to find one or more unknown code symbologies on an acquired image.

Reading Phase: this group manages the operating mode for image acquisition.

Good Read Setup: this group manages data collection: Code Collection, Code Combination, Code Presentation, or Match Code.
Data Formatting: this group manages the output message to the Host.

Output Setup: this group manages the digital outputs as well as the Green/Red Spots.

CHAPTER 2 INSTALLATION

DL.CODE DISTRIBUTION CONTENTS

The DL.CODE program distribution contains the following:

• Complete Installation of DL.CODE

• .NET Framework (if not already present)

• Technical documentation, including this manual

HARDWARE REQUIREMENTS

Typical hardware requirements for a DL.CODE Client PC are:

• 2.00 GHz or faster microprocessor

• 1 GB RAM

• 2 GB hard disk for 64-bit machines; 1 GB hard disk for 32-bit machines

• 100 Base-T Ethernet

• One 19” or larger monitor (optimized for 1280x1024 resolution)

NOTE: The installation of DL.CODE requires about 1 GB free space in the Windows installation drive, because during installation Windows itself requires 1 GB of space on the drive (e.g. C drive). This space is then partially released after instal- lation (some of it remains occupied with an installer backup for future uninstalla- tion).

This is in addition to the 500 MB of space required in the DL.CODE installation folder (which can be changed).

INSTALLATION

SOFTWARE REQUIREMENTS

• One of the following Windows Operating Systems (32 or 64-bit):

- Windows 8

- Windows 10

NOTE: The Windows XP and Windows 7 operating systems are no longer supported by DL.CODE.

• Web Browser: Google Chrome, Mozilla Firefox, Microsoft Internet Explorer, Opera, etc.

NOTE: The Google Chrome Web Browser is recommended for its superior performance characteristics**.**

CAUTION: DL.CODE does not currently support Windows Embedded (often used in industrial PCs and/or PLCs).

INSTALLING DL.CODE

NOTE: Starting from version 1.5.0, multiple versions of DL.CODE can be installed on the same PC. Each version will be installed in its own folder, however only one version can be run at a time**.**

Standard Installation

On the PC that will be used for configuration (running 8 or 10), download the DL.CODE mini-DVD .zip file. Extract the files maintaining the folder structure and run the start.hta file to access the installation pop-up. Click on the Install DL.CODE link to run the installation program and follow the installation proce- dure.

NOTE: If you need to configure Serial models, check the RS232 Serial Port Driver installation box in the Welcome window of the DL.CODE Installer**.**

NOTE: If you need to configure USB models, check the Matrix USB Driver installation box in the Welcome window of the DL.CODE Installer and follow the procedure given in the specific reader Reference Manual.

When the installation is complete, the DL.CODE entry is created in the Start>Pro- grams bar under “Datalogic” as well as a desktop icon. Double-click the desktop icon to run it.

Silent Installation

UNINSTALLING DL.CODE

A silent installation which requires no input from the user can be run from a command line prompt. You must have Administrator rights on the PC for this installation. There are two options:

• Quiet: this does not display any user interface.

• Passive: this displays the user interface but proceeds without requiring any user input.

Open a command line prompt clicking the Win+R keys.
Set the directory to where the extracted DL.CODE setup package is located.
Invoke the package with double quotes “ ” and either /passive or /quiet switches.

UNINSTALLING DL.CODE

To completely uninstall DL.CODE including software drivers from your PC, you must use the following sequence:

Uninstall all versions of DL.CODEfrom your PC from the Control Panel.

Uninstall the com0com driver from the com0com folder in Windows Start Menu – All Programs.
Uninstall the USBCOMInstaller from the Control Panel.
Uninstall the cdcecmInstaller from the Control Panel.

NOTE: Trying to uninstall software drivers before all versions of DL.CODE are uninstalled will cause an error.

第3章快速入门

为了助您入门，此处提供了一份配置示例，演示了 DL.CODE 配置的基本步骤。

若要使用 DL.CODE 为您的应用配置设备，需假定已完成以下预备步骤：

读取设备已安装并正在运行。
DL.CODE 已安装并正在运行（第 2 章）。

以太网设备发现

NOTE: To discover Serial models see "Serial Device Discovery" on page 16. To discover USB models, see the specific reader Reference Manual for details.

The User Interface opens and displays a list of all the devices belonging to the Local Area Network. DL.CODE has a discovery feature to accomplish this task.

Figure 9 - Device Discovery

The discovery feature will also show devices not belonging to the LAN and display them in gray (see Figure 9).

The following procedure will demonstrate an example configuration.

First, the device must be added to the LAN by aligning its IP Address to the net- work. The network administrator should provide valid LAN address(es).

Click on the device wrench icon to open the Device Environment Configu- ration window.

Change the Ethernet Settings (IP Address, Subnet Mask, Gateway Address etc.) according to the network requirements. See also Figure 10 below.

Figure 10 - Device Environment Configuration Window

Click OK; the device will reappear in the list of Online Devices (in color) meaning it is now part of the LAN and can be configured. The new IP address will also be dis- played.

Double-click on or drag the device icon into the Selected Device Information Area. Details about the device will be displayed in this area.

NOTE: After device discovery, configure your device through DL.CODE as described in Decoding Configuration Parameters, Operating Mode Configu- ration Parameters, and Output Configuration Parameters.

串口设备发现

Starting from DL.CODE 1.4.0, serial port communication is supported for device discov- ery and configuration. This allows dedicated serial communication models to be config- ured through DL.CODE

NOTE: Although this feature allows all devices to be configured through their Serial Interface, be aware that transmission speeds and some DL.CODE features are limited when using this interface. It is always advised to use the Ethernet interface whenever possible.

This feature is not enabled by default, so the first thing to do is to enable it through the UI Settings window.

From the main menu open the Options

> UI Settings Window.

Click on the Global Settings menu and scroll down to the Find Devices tab.

Check the Enable Serial Device Discov- ery box. Scroll down to see the follow- ing selections.

Select the Serial communication parameters according to your applica- tion.

NOTE: If you’re not sure of the Serial baud rate you can also check the Enable Automatic Device Discovery box which for serial devices will try communication at all baud rates, but only at No parity, 8 data bits;1 stop bit.

Enabling this parameter can notably lengthen Discovery time, therefore in general it is better to disable it to increase Discovery efficiency.

Click OK to return to DL.CODE and click on the Getting Started icon.
Open the Serial devices tab and double-click on or drag the device icon into the Selected Device Information Area.

The device is now connected to the DL.CODE Configuration environment. Configure your device through DL.CODE as described in Decoding Configuration Parameters, Oper- ating Mode Configuration Parameters, and Output Configuration Parameters.

DECODING CONFIGURATION PARAMETERS

The Decoding Configuration parameters are divided into two groups: Automatic Setup

and Manual Setup.

Automatic Setup

Automatic Setup uses up to two different algorithms for the automatic setting of opti- cal, illumination and code parameters to achieve the most stable reading conditions.

Standard Automatic Setup (available on all products) can read one or more of the code symbologies from the table below. It can be set to include Image Filters if necessary.

Enabled 1D Codes	Enabled 2D Codes	Enabled Postal Codes
CODE 128	DATAMATRIX	POSTNET
CODE 25	QR	PLANET
CODE 93	AZTEC
CODE 39	MAXICODE
CODABAR	DOTCODE
INTERLEAVED 2 OF 5
UPC/EAN
MSI
PDF
GS1 DATABAR

The DPM Automatic Setup (available on M220X / XP, M320X and M220X-AI) is able to read one of the symbologies from the table below. It is recommended for reading diffi- cult-to-read 2D codes on Direct Part Marking applications.

Enabled 1D Codes	Enabled 2D Codes	Enabled Postal Codes
/	DATAMATRIX QR	/

NOTE: With M220X, M220X-AI, M320X, it is possible to use both Standard and DPM setup.

With all other models, only the Standard setup will be available for use.

Manual Setup

Manual Setup provides access to the complete array of optical/illumination and code definition parameters that can be fine-tuned semi-automatically and manually to obtain the best results for applications of any complexity.

NOTE: If your application requires multiple code symbologies, multiple Image settings, Code Grading or other parameter settings for decoding, then use the Manual Setup (see Manual Setup Configuration, starting on page 29).

Automatic Setup Configuration

To begin configuration, the reader must be correctly mounted so that its Field of View covers the application reading area.

NOTE: Automatic Setup is not available with Blade.

From the Task Area select Open Device Configuration.

The Open Device Configuration window opens showing the list of currently saved configurations (jobs) saved on the device. For new devices, the only saved job is the Default configuration. Click OK. The device enters run mode and begins acquir- ing images.

Place the application code in front of the reader at the correct application reading distance.

Click on the Pause button to stop image acquisition.

NOTE: Step 4, Clicking on the Pause button is optional.

Before proceeding with the automatic setup, you must set the focus first. Click the Focus button. A green line alerts you when the procedure is complete.

Now click on the Start Automatic Setup button.

The following window is displayed and the reader begins acquiring images.

NOTE: Depending on the algorithm, certain phases may not be displayed.

At the end of the procedure the Automatic Setup Completed! message appears.

When the automatic setup is complete, a result table is displayed containing the image setup, symbology, and code properties.

Your reader is now optimized for decoding. Continue with the Operating Mode configu- ration described in Operating Mode Configuration Parameters.

Error during Automatic Setup

If the Automatic Setup cannot find the code, the following message appears.

Advanced Options

If you need more configuration options, click the Advanced Options button. Depending on the connected device, different configuration labels are displayed.

NOTE: The GUI shown below for Advanced Options is valid for firmware later than 1.12.8 and later than DL.Code 1.13.2.

Static vs Dynamic

The advanced options allows you to choose between Static and Dynamic Tuning. If your application involved moving codes, the Dynamic option must be selected to avoid a blurring effect on the image.

Figure 11 - Dynamic Tuning

NOTE: If you select the Dynamic option, two parameters must be set: Max Line Speed and Code Resolution

Autosetup Region

This option allows you to set an area of interest (ROI) on which the autosetup algorithm will focus exclusively to search for the barcode.

During the autosetup procedure, the area of interest will be temporarily hidden and shown again at the end.

At the end of the procedure, the system is configured to decode any barcodes present within the selected ROI.

Figure 12 - Autosetup Region

NOTE: The new settings are applied, so any other barcodes present in the image that can be decoded with the result of the procedure can also be decoded.

Advanced Options for M220X/M220X-AI/M220XP and M320X

The following options are displayed.

NOTE: For American and Japanese users, the label for Polarized Illumina- tion is displayed.

Figure 13 - M220X/M220X-AI/M220XP and M320X Labels

Advanced Options for All Other Models

When using a model that is that is neither M220X/M220X-AI/M220XP nor M320X, the following options are displayed.

Manual Setup Configuration

If your application requires multiple code symbologies, multiple image settings or other parameter settings for decoding, use the Manual Setup.

Click on the Manual Setup button and press the Play icon.
Place the Grade A Barcode Test Chart in the reading area. Once positioned, stop image acquisition by clicking on the Pause button.

Click the Image Settings branch and then click the Image Auto-Setup button to automatically acquire the best exposure time and gain values.

Select the Static or Dynamic Self-Tuning option; Start the Image Auto Setup and Apply to the Image Settings.

NOTE: For applications having multiple lighting or code reading conditions, up to 10 different

Image Settings can be configured by adding them with the icon.

For the next step you need to enable the Focus Calibration Tool from the Options>UI Settings Configuration tab if not already enabled.

Now click on the Focus Calibration tab at the bottom of the window. The oscillo- scope view is shown in the bottom panel and can be used for manual focus adjust- ment.

The red line in the image panel above the oscilloscope must pass through the code. You can click and drag the red line vertically to reposition it over the code.

If the “Focus” is orange or red, the code is not focused properly. The code is focused when both the Focus and the Peak values are green.

You can enlarge the visual image of the code and the oscilloscope views, you can drag the Focus Calibration window up and click on the zoom image

icon repositioning it on the code.

While in run mode, manually adjust the focus until the bars relative to the code in the oscilloscope demonstrate their maximum length (focus).

You can also see the visual focus on the code view.

When focused, click Pause to stop image acquisition.

Click the Acquire PPI button to automatically set Image Density so that reader will function correctly and to the fullest extent of its capabilities. This procedure is necessary for first time installations, or if the focal distance is changed.

NOTE: At this point it is probably a good idea to save the configuration from temporary memory to permanent memory giving it a specific name.

Now place an application specific code in front of the reader and only click the Image Auto-Setup button to register any changes in lighting or code surface con- trast. Do not repeat Focus Calibration or PPI.

Click on the Datamatrix symbology under the Image Settings branch (enabled by default). If this symbology is among those in your application it will be shown in the image display with its code symbology name and a green box around it indi- cating it is decoded.

NOTE: The large green box for each symbol indicates the code localization area which by default is equal to the maximum FoV. It can be resized and moved by dragging its borders with the mouse. The code must be found within this area in order to be decoded.

Add your application specific codes to the Code Settings by selecting them from the icons over the Configuration Parameters tree area. If the Data Matrix symbol- ogy is not used, then delete it from the Code Settings with the Delete icon.

If you don’t know the code type, you can use the Code Autolearn feature by click- ing on the Autolearn icon.

See "Code Autolearn Feature" on page 58 for details.

For each symbology set the relative parameters according to your application.

OPERATING MODE CONFIGURATION PARAMETERS

Reading Phase

Select your application specific Operating Mode from the icons over the Configu- ration Parameters tree area: Continuous, One Shot, Phase Mode or PackTrack.

Configure the relative Operating Mode parameters from the Reading Phase parameters panel. Different groups will appear in the panel depending on the selected icons over the Configuration Parameters tree area.

CAUTION: If the same signal activates multiple events with the same edge, those events are fired in a random order.

If the same channel activates multiple events with the same string, those events are fired in a random order.

AVOID doing this action. The reader may not work properly, the result is not predictable!

Good Read Setup

OPERATING MODE CONFIGURATION PARAMETERS

Select your specific data collection type from the icons over the Configuration Parameters tree area: Code Collection, Code Combination, Code Presentation or Match Code. Not all data collection types are available for all Operating Modes; for example PackTrack Operating Mode only supports Code Combination. Incom- patible data collection types will be shown in gray and cannot be selected.

The following example shows Code Combination. By default, the Expected Codes (when more than one code type is selected), are in logical AND, which means that all codes are required to be decoded to produce a Good Read condition.

If a Good Read condition should be produced when any single code is decoded, independent from the others, then they need to be combined in logical XOR. To do this, drag the code icon(s) from their relative Expected Code box into the Expected Code box of the XOR combination you wish to create. Then delete the empty box by selecting it with the mouse (highlighted) and pressing the delete key on your keyboard.

To create a logical AND condition from a logical XOR, create a new Expected Code box using the Add icon. Then drag the desired code from one box to the other.

OUTPUT CONFIGURATION PARAMETERS

Data Formatting

Configure your application specific Data Formatting Message(s) from the Configu- ration Parameters tree area: Message 1, Message 2, etc.

You can add fields to the output message by clicking on the icons above the Message Field area. They will be appended to the message. You can drag them to position them between other fields in the message so that the output message is ordered according to your application requirements.

Each field has its own relative configuration parameters in the parameters panel.

Output Setup

OUTPUT CONFIGURATION PARAMETERS

Configure your application specific Digital Output(s), Green/Red Spots and 360° Feedback (depending on Matrix model) from the Configuration Parameters tree area: Output 1, Output 2, etc.

NOTE: Save the configuration from temporary memory to permanent mem- ory, overwriting the previously saved configuration.

CHAPTER 4 DL.CODE USER INTERFACE

DL.CODE DEVICE DISCOVERY WINDOW

After loading your specific device from the discovery window (drag & drop from the Device Selection Area), the DL.CODE Device Discovery window presents the following principal areas:

• Main Menu and Toolbar Area – allows access to the major program functions and commands. See "DL.CODE Main Menu and Toolbar" on page 46.

• Device List Area – shows all the discovered devices both on and off the LAN. The colored icons next to the device labels indicate network status, see "Device List Area" on page 42. Double-clicking or dragging an available device icon onto the Device Information Area connects it to DL.CODE for configuration.

• Device Information Area – this area shows all device specific information: Name, Model, Role, running software and version details.

• Task Area – Presents a graphical list of the main features to be performed upon device connection: create a new configuration (Stand Alone or Master/Slave), Open an existing configuration, perform PackTrack calibration, or switch to Moni- tor mode. These selections are also available in the File and Device Menus.

• Control/Help Panel – In the DL.CODE opening window this panel provides a Help description for Device Selection. Once a new or existing configuration is loaded, this is the key area which allows all the individual device configuration parameters to be set. Context sensitive Help is also available from this panel. See "Control/Help Panel" on page 44.

• Status Bar – a reserved area that keeps specific information about the connected device: Name, Model, SN, IP Address, Device SW version, user level, and DL.CODE program version always visible.

Figure 14 - Device Discovery Window Areas

Device List Area

The Device List area shows all the discovered devices both on and off the LAN. The icons indicate the Device status as shown in the table below:

Online Device Sorting

From software version 1.9.2, the list of online devices can be sorted by Serial Number (SN), Family (device model), IP Address, and Device Name.

Sorting is only applied to first level devices, i.e. Standalone and Master devices, while Slave devices are always sorted by Slave address.

At each application launch, the last sorting used will be applied.

Wink and Web Monitor icons

The device tree area shows the Wink and Web Monitor icons next to all devices support- ing these functions, as shown in the figure below:

Clicking on the Wink icon makes the device screen or on-board LEDs flash for 3 sec- onds. Where available, the 360° Visual Feedback will blink too.

The Wink function is also available in the Internal Network Configurations view:

Control/Help Panel

Upon opening DL.CODE, the Device Selection Help Page is displayed with dropdown descrip- tions briefly explaining how to connect to your device and the various configuration selections. Click on the icon to open the dropdown description.

You can also click on the Show All link at the top of the Help page to open all collapsed text descriptions.

When a new configuration is created or an existing one is opened, the Control page showing all of the configuration parameters for the selected configuration step or item is displayed in the Help/Control area.

By clicking on any parameter name with a hyperlink, the relative contextual help page will open and present the specific parameter description.

Figure 15 - Control Panel and Relative Contextual Help Page

To return to the parameter page, click on the Control bar.

The Main Menu and Toolbar icons are located at the top of the DL.CODE window as shown below.

The Main Menu presents the following items:

File:

• Getting Started: returns to the initial Device Discovery window to load a different device. You will be prompted to Save or Discard the current configuration.

• Open: load a previously saved configuration from the device memory or from a

.dlcfg file selected from a disk/directory of your choice.

• Save: save the current configuration to the device memory or to a .dlcfg file selected from a disk/directory of your choice.

• Setup Internal Network: sets the current device’s internal network Role to Master and performs the Net Auto-set feature to automatically recognize its connected ID-NET Slaves. The Internal Network Configuration window allows ID-NET configu- ration management. See "Multi Device Configuration Options" starting on page 146 for details.

• Monitor: sets the device to run mode for testing configuration results. An image window is displayed along with Statistics, Diagnostics and a Console for output message verification. See "Monitor" starting on page 126 for details on using and configuring the Monitor.

• Exit: exits the DL.CODE User Interface.

Option:

• Change Language: allows you to change the display language used for DL.CODE in real time. The selected language will also be used for successive sessions.

• UI Settings: opens a window where various settings can be made regarding DL.CODE presentation on the PC. The following DL.CODE features can be config- ured: console presentation, Image Buffer positioning and behavior, Simulator Set- tings, and selecting which features to enable for viewing. The Monitor can also be configured from this window by selecting the Monitor tab.

• Log: allows the configuration log level to be changed between Verbose, Informa- tion and Error.

• Change User: allows the configuration access level to be changed between Basic- User (no parameters modification allowed), Basic-Installer (medium level of parameter modification allowed) and Expert-Installer (maximum level of parame- ter modification allowed).

• Restore UI to Default: restores all UI panels to their default positions.

Device:

• Connect to Device: if not already connected to a device, this allows you to connect to a device on the LAN by inputting its IP Address into the dialog box and clicking Connect.

• Find Devices: searches for new devices connected to the LAN without disconnect- ing from the current device.

• Settings: opens device configuration windows for configuring Environment param- eters (see "Device Configuration Settings" starting on page 202), Advanced Configu-

ration Settings, resetting Statistics and/or Diagnostic counters and viewing HMP shortcuts.

• Update Package: allows updating the device firmware (application program, schema, etc.) either upgrading or downgrading to a different version, see also Caution below. For the complete procedure, see "Update Package" on page 220

• Multi-Device Package Update: allows updating multiple devices simultaneously. This command is only available when no device is currently connected to DL.CODE. Update firmware (application program, schema, etc.) either upgrading or downgrading to a different version, see also Caution below.

After selecting the package to update, select the devices from the list in the Mult- Device Package Update window. When updating is completed the window reap- pears indicating success or failure for each device.

• Change Current Configuration

• Restart Device: performs a software reset on the loaded device.

• Backup/Restore: manages all the backup and restore options to and from the device as well as restoring the default settings.

• RAM Image Buffer Settings: opens the RAM Image Buffer Management window to either save or discard images in the device’s RAM Image Buffer.

• PackTrack Calibration: launches the Packtrack Calibration procedure. See "Pack- track Calibration" starting on page 170 for details.

Documentation:

• allows to have access to device documentation.

Help:

• About: opens the information window containing the DL.CODE program release version number.

• DL.CODE User’s Manual: opens this manual.

Toolbar buttons:

User Levels

DL.CODE has a 3-level user interface (Basic User level, Basic Installer level, Expert Installer level).

Each level can be accessed by selecting it from the Options Menu. The User levels have the following access rights.

Basic User: only access to the Monitor feature is given. No device configuration.

Basic Installer: a subset of program features and configuration parameters is allowed.

No Master/Slave configuration, no multiple Image Settings configurations, no Postal Codes configuration, no Fieldbus configuration.

Expert Installer: access is given to all program features and configuration parameters.

MULTI IMAGE ACQUISITION SETTINGS

When controlled variable conditions occur in the application, Multiple *Image Acquisi- tion* *Settings* can be defined to create a database of parameter groups that handle each specific application condition. This database of pre-defined settings improves system flexibility and readiness by being applied either automatically or selectively by an activa- tion event.

For example, an application may have several stable but different lighting conditions which require different lighting options. One Image Acquisition Setting could enable and use an internal illuminator and another setting could enable and use an external lighting system.

This feature is available for all Operating Modes.

*Image* *Settings* are found in the DL.CODE Manual Setup step. Up to 10 different Image Settings can be configured by adding them with the Add icon.

For each Image Setting condition start Image Auto Setup, select the Static or Dynamic Self-Tuning option and Apply it

NOTE: The Automatic Setup procedure can be used for each Image Setting that is added through the Manual Setup group, however only one code will be associated with each Image Setting.

Automatic Image Settings Selection

If we don’t know from one item to the next which reading condition will be presented, we will cycle through the pre-defined database of Image Settings (one per acquisition) in order to automatically capture the correctly lighted image over the course of several acquisitions. When the correct condition is matched, the result should be able to pro- duce a Good Read.

When the Image Settings Selection is Automatic (default), then these Image Settings groups will be used cyclically.

NOTE: Applications typically require more than one acquisition to obtain suf- ficient Good Read percentages. This means that for N acquisitions we will surely have captured the correct lighting condition but we will also have captured some acquisitions with the wrong lighting condition. A conse- quence then is that we cannot run these types of applications at the maxi- mum speed because not all the acquisitions are useful to us. We must wait for a sufficient number of acquisitions that will guarantee a Good Read result.

If items to be read having the same lighting conditions are grouped together, then we can improve the read rate through the Start Acquisition From parameter. By choosing the Last Successful value, we will start with the Image Setting that last produced a Good Read. For this group of items the last Image Setting used will be correct for the next item and so we start each cycle with the acquisition that will potentially produce a Good Read.

External Image Settings Selection

There are some applications where the lighting conditions are known before each item is read and therefore we can pre-select the correct Image Setting from an external source.

When the Image Settings Selection is External, Acquisition Sequences are created and by default each Image Setting has its own Acquisition Sequence.

Each Acquisition Sequence can be activated exclusively by a single event, either through a string from an available communication channel or by a digital input.

Alternatively, a hybrid configuration can be made where more than one Image Setting can be grouped into an Acquisition Sequence by dragging it into the desired Sequence box. Select the empty Sequence box and delete it with the delete key.

Each Acquisition Sequence can be activated exclusively by a single event, either through a string from an available communication channel or by a digital input.

In this case the Start Acquisition From parameter can improve the read rate for that Sequence. It has no meaning for a Sequence containing only one Image Setting.

IMAGE CROPPING

In some applications, the Image Cropping feature in DL.CODE can help to increase decoding and result performance. Image cropping is performed from both Manual and Automatic Setup tab by clicking on the Add Cropping Region icon as shown below.

Image cropping allows reducing the Image processing area from the full FoV to a smaller area where codes are present. By excluding portions of the FoV, processing time is reduced.

After clicking the Add Cropping Region icon, a blue border appears which by default is equal to the FoV.

By dragging the edges with the mouse (resizing) you can crop the image to a specific location where codes are present. The numbers in the blue boxes refer to pixel refer- ences.

The cropped area can be moved by dragging its center.

You can also set the cropped image size and position through the Cropping Region Area group of parameters; size = Width and Height, position = Left, Top (x,y) coordinates.

CODE AUTOLEARN FEATURE

From the Manual setup page, you can run the Code Autolearn feature which will recog- nize all the codes present in the captured image.

From the Manual Setup page, click on the Autolearn icon and select Code Autolearn.

The Autolearn region (equal to the FoV) is shown in grey. You can reduce and/or move the search area by dragging the borders or the center of the area with the mouse.

• Reducing the area can reduce the time necessary to find the code(s).

• Moving the search area allows finding specific code(s) in the image.

CODE AUTOLEARN FEATURE

Whether the area is reduced or not, you can start the Autolearn feature by clicking on the Autolearn icon in the display area.

Each Autolearn iteration locates a single code symbology and you will be prompted to Continue (if you need to find other codes) or to Finish.

When you have located all the code symbologies, click on Finish. You will be prompted to choose a saving selection.

IMAGE FILTERING

Image Filtering is typically done in DPM applications where the marking technique pro- duces module shapes or textures that can make decoding difficult. Special DPM algo- rithms are provided to improve decoding as well as pre-processing Image Filters which modify the image to compensate for defects.

The following paragraphs detail the DPM parameters used to enhance decoding capabil- ities.

DPM Algorithms

For Data Matrix family codes the *Decoding Complexity* parameter is available when Processing Mode is set to Standard and selects the decoding algorithm according to the printing/marking technique used to create the symbol and on the overall printing/ marking quality.

The possible selections progress from Low to Very High where Low can improve decod- ing time for good print/mark quality and/or relatively normal size codes. This is the default setting. Very High can improve the decode rate for low print/mark quality and/ or small size codes. This algorithm is much more aggressive but in general it may have longer decoding times than the lower complexity algorithms. To minimize decoding time it is better to select the lowest value that still guarantees good decoding.

Figure 16 - Problematic Direct Part Marking Examples

For QR code the *Decoding* *Method* parameter allows the Dot Peen Decoding algorithm to be selected which improves the decode rate for low quality Direct Part Mark codes and in general for Direct Part Mark codes with dot peening type module shapes.

Image Filters

In DL.CODE, when Image Filters are used, they are always applied relative to a specific code symbology or group of symbologies depending on the nesting logic applied to the tree structure. See “Image Filter Setting Examples” on page 65.

The following Image Filters can be applied to DPM codes to improve decoding.

Image Filter

Sets the filter to be applied to the image before being processed. This parameter can be used to successfully decode particular ink-spread printed codes (ex. direct part mark codes).

Different filters can be applied to a single code or group of codes in one or more Image Settings. See “Image Filter Setting Examples” on page 65.

The *Erode* filter enlarges the image dark zones to increase readability.

Before - No Read

Erode

After - Readable

The *Dilate* filter enlarges the image white zones to increase readability.

Before - No Read

Dilate

After - Readable

The *Close* filter eliminates dark areas (defects) in the white zones of the image.

Before - No Read

Close

After - Readable

The *Open* filter eliminates white areas (defects) in the dark zones of the image.

Before - No Read

Open

After - Readable

The Contrast Stretching filter maximizes image contrast.

Before - No Read After - Readable Contrast Stretching

The *Histogram* *Equalization* filter makes the gray level distribution uniform.

Before - No Read After - Readable Histogram Equalization

The Smoothing filter deletes small (insignificant) details in the center of the image.

Before - No Read

Smoothing

After - Readable

The *Sharpening* filter improves out of focus images.

Before - No Read

Sharpening

After - Readable

The *Deblurring* filter improves blurred images.

Before - No Read

Deblurring

After - Readable

The *Black Enhancement* filter produces a nonlinear increase in the black level for light images.

Before - No Read

Black Enhancement

After - Readable

The *White* *Enhancement* filter produces a nonlinear increase in the white level for dark images.

Before - No Read After - Readable White Enhancement

Image Filter Setting Examples

Example 1

To demonstrate how to apply an Image Filter through DL.CODE, the following example shows a hypothetical application in which a Data Matrix ECC 200 DPM code and printed label codes (QR Code and Code 128) must be decoded in the same image. In this exam- ple the codes can be found in any area within the image.

To correctly decode the Data Matrix ECC 200 DPM code, an Image Filter needs to be applied.

Since all codes can be found in any area of the image, both Code Localization and Filter Application boxes will be left at their default values, all covering the entire image area. The resulting image is shown below.

NOTE: By leaving the Filter Application box at its default value, covering the entire image area, you will see the visual filter effects on the entire image, seemingly affecting the other codes, however this pre-processing filter is only applied to the Data Matrix ECC 200 code as shown in the configuration parameter tree. The filter is not applied to Code 128 and QR Codes.

Since the visual effects in the image area are over- lapped, you should not use this as a reference to determine how and where Image Filters are applied. You must read Image Filter application from the Tree structure in the configuration parameter tree area. The example in the figure to the left shows:

• Code 128, QR1 and Code 39 at the Image Set- tings level = No Image Filters applied.

• DMECC200 has the Close Filter applied to it.

• QR2 has the Histogram Equalization Filter applied to it and it is also nested under the Close Filter, so both filters apply to QR2.

The following steps are taken to apply the Close filter to Example 1:

From the Image Settings group, add the Code Symbologies that must be decoded: Code 128, DMECC200 and QR Code. The Code 128 and QR Codes are successfully decoded; Code Localization boxes as well as code bounding boxes are colored green.

Select the Data Matrix ECC 200 code and add the Image Filter. Notice that the Data Matrix DPM code is not successfully decoded, Code Localization box is col- ored red.

Select the desired Image Filter Type and Intensity for correct decoding.

The Data Matrix DPM code is now successfully decoded. The Code Localization box and the Code Bounding box are both colored green.

Example 2

This example is based on the previous one except that each of the three code symbolo- gies will always be located in a specific physical area of the image and must not be decoded out of its expected position.

In this case, not only do we need to apply an Image Filter to the Data Matrix ECC 200 DPM code, but we need to set the Code Localization and Filter Application box sizes and positions to their respective image area to prevent decoding a code if it is in the wrong position.

The following steps are taken to apply the Close filter to Example 2:

From the Image Settings group, add the Code Symbologies that must be decoded: Code 128, DMECC200 and QR Code.

For each one of them, resize and position its code localization box (dragging its borders with the mouse or editing the Code Localization Box parameters) to the image area where the code will be found.

Select the Data Matrix ECC 200 code and add the Image Filter.

Resize and position the filter application box (dragging its borders with the mouse or editing the Filter Application Box parameters) to the image area where the filter will be applied. The relative Code Localization box must fit inside its Filter Applica- tion box.

Select the desired Image Filter Type and Intensity for correct decoding.

The Data Matrix DPM code is now successfully decoded only within the expected posi- tion. The Code Localization box and the Code Bounding box are both colored green.

MATRIX CONTROL BY FIELDBUS CHANNEL

The Matrix reader can be controlled by signals coming from the Fieldbus Master as well as echoing its input signals to the Fieldbus Master.

Fieldbus Input/Output Representation in DL.CODE

For HMS Fieldbus and the embedded Profinet-IO channels, communication with the Matrix reader takes place through Input/Output Exchange Areas. The size of these areas must be correctly defined in the relative parameters (see below). See also "Digital IO Conditioning" on page 73 to account for Digital IO Conditioning.

The Input and Output Exchange Area Size parameters refer to the Fieldbus Master, Input

to the Master, Output from the Master.

NOTE: All other representations in DL.CODE show the Fieldbus input and output channels from the Matrix reader perspective (Fieldbus Slave Node). Therefore, Fieldbus slave node Input Bits are from the Fieldbus Master and Fieldbus slave node Output Bits are to the Fieldbus Master.

NOTE: When Profinet IO is enabled, the device communication is limited to the local network even if a Gateway is set.

Digital IO Conditioning

When checked (enabled by default), this parameter reserves the first byte of the Input/ Output Areas for the Host to receive device Input echoes, drive the device Reading Phase and/or drive the device Outputs.

In this case application data or Data Flow Control begin at the second byte of the Input/ Output Areas. For more details on Data Flow Control refer to the "DAD Driver" docu- ment included in the DL.CODE installation package.

NOTE: By disabling Digital IO Conditioning, application data or Data Flow Control begin at the first byte of the Input/Output Areas. Any Digital IO Con- ditioning configurations (Input echo, Reading Phase or Output control from the Fieldbus Host) will be ignored.

Fieldbus Reading Phase Control

The Fieldbus Master can control the reading phase by assigning either communication strings or individual communication bits to reading phase parameters. These bits are received on the Matrix Fieldbus channel as Input Bits.

Fieldbus Digital Output Control

The Fieldbus Master can also drive the Matrix reader’s Digital Outputs by assigning either communication strings or individual communication bits to the Digital Output Activation and Deactivation parameters. These bits are received on the Matrix Fieldbus channel as Input Bits.

Digital Input Echo to Fieldbus

The Fieldbus Master can receive the Matrix Reading Phase and Input signal echoes by assigning them as sources to the Fieldbus individual communication Output Bit Activa- tion and Deactivation parameters. These bits are sent on the Matrix Fieldbus channel as Output Bits.

TEST MODE

Test Mode allows you to test the reading performance of your system:

To enter Test Mode, click on the icon accessible from the Automatic or Manual Setup step:

When entering Test Mode, the configuration is saved in Temporary Mem- ory.

NOTE

To exit Test Mode, click on the icon:

The Test Mode area is displayed underneath the image and shows the following ele- ments:

A quality indicator representing the decoding rate within a specified time frame. This can be set with the “Number of Samples” parameter in Device > Settings > Settings > Device Environment Settings (see "X-PRESS Configuration" on page 212).
A graph showing the trend in decoding rate.
The content of the last decoded code (blank in case of decoding failure).
The time taken for the last decoding.

BACKUP AND RESTORE THROUGH DL.CODE

DL.CODE allows Backup and Restore to be performed to the configuration PC via file or to an external storage device such as BM100.

It can be performed for Single Reader and Internal Network (Master/Slave) configura- tions.

Backup and Restore functions allow performing Complete Configuration and Environ- ment parameter storage for Single Reader and ID-NET (Master/Slave) network devices as well as device firmware. Backup and Restore can be applied to any reader connected through a device having external backup memory, regardless of the reader's network configuration.

Backup to and Restore from external device is supported by DL.CODE for all reading devices when connected to:

• CBX + BM100

• QLM-Series Gateways

NOTE: Before executing a Backup to a BM100 backup module make sure the Write Protection switch is set to Unlocked.

Backup

To perform a Backup:

From the DL.CODE Device menu, select either Single Reader Backup (to file on PC) or Backup to external storage device.

NOTE: For ID-NET network Backup, select the Backup current Internal Net- work configurations selection.

You will be reminded that configuration in temporary memory will no be saved so you should save the configuration to the reader before performing Backup:

If you are performing a backup to a file, you will be asked whether to include the firm- ware or not.

At the end of the backup, DL.CODE shows a message indicating successful completion.

Restore

CAUTION: The restore procedure cannot be performed on different models, but only on one same model.

To perform a Restore:

From the DL.CODE Device menu, select either Single Reader Restore (from file on PC) or Restore from external storage device

NOTE: For ID-NET network Restore, select the Internal Network replace- ment selection.

If restoring an ID-NET network though the Master, this may take a few minutes.

At the end of the restore, DL.CODE shows a message indicating successful completion.

Replacement

CAUTION: The replacement device must be the exact same model as the device it is replacing.

The Restore function also provides easy and secure Single Device Replacement:

Remove the device to be replaced.

Connect the new device (make sure the new device has been previously set to fac- tory default).

Run the Restore procedure by selecting either Single Reader Restore (from file on PC) or Restore from external storage device item (see: Restore procedure).

NOTE: In case of Backup or Restore operation failures, error messages will be displayed in the Monitor Diagnostic page.

RESTORE DEFAULTS

The device parameters are divided into two main classes, Configuration and Environ- ment which are affected differently by the Restore Defaults commands.

• The Configuration parameters are the ones set in the various steps of the configu- ration process and are specific to each application. When multiple configurations (jobs) are saved on a single device, these parameters can be different from one configuration to the next.

• Environment parameters regard the device Identity and Position in a Network (Ethernet, ID-NET, etc.) and are not influenced by the Default (or any other) Con- figuration present in memory.

Restore Default Startup Configuration

The Default configuration is always present on the reader and in fact it is not modifiable and cannot be deleted. It can always be restored by simply selecting it from the Open from Device configuration list.

The same action can be performed from the Device menu >Backup/Restore > Restore Defaults > Restore Default Startup Configuration. The Default Configuration will be set to run at startup and the reader will be reset.

Any previously saved configurations on the device will remain in memory, but the Default configuration is set as the startup configuration.

Restore Default Environment

RESTORE DEFAULTS

Restore Default Environment returns all Environment parameters to their factory default settings. The default IP address will be restored as well as all the parameters managed in the Device Environment Configuration window.

The Factory Default static IP address for all Matrix N Family readers is:

IP Address = 192.168.3.100

Any previously saved configurations on the device will remain in memory, but the Default configuration is set as the startup configuration.

Restore Factory Defaults

In order to return a device to its absolute Factory default parameters (for example device replacement) it is necessary to use the Restore Factory Defaults command. You will be prompted to confirm.

All Environment parameters will be restored to Factory default values and any existing configurations stored on the device will be erased. The device will be reset and there- fore start in run mode with the factory default configuration.

Software Reset

At any time the device can be reset by the Restart Device command in the DL.CODE Device Menu.

CAUTION: Remember to save the current configuration before restarting.

WEB MONITOR

The Web Monitor is a remote monitoring tool provided to visualize the Matrix reader in its run-time environment. You can access it from the DL.CODE Task area or directly from your browser by inputting the IP address of the reader. The reader must be available on the LAN.

This works on major browsers (also on smartphones and tablets), which support HTML5 (see the table below).

Chrome	Firefox	Edge	IE	Safari	iOS	Android	IEMobile
latest	latest	14	11	10	10	Nougat (7.0)Marshmallow (6.0)	11
		13	10	9	9	Lollipop (5.0, 5.1)
			9	8	8	KitKat (4.4.)
				7	7	Jelly Bean (4.1, 4.2,4.3)

NOTE: If you use Web Monitor with a simulator reader, make sure that port 80 of your computer is free. If port 80 is busy, you will not be able to access the Web Monitor page of the selected simulator.

The Web Monitor tool provides the following features:

Info page

Monitoring Page

Statistics Page

Diagnostics Page

The Web Monitor tool also provides a page for Code Grading Monitoring and a Configu- rator to edit your Matrix reader settings. To access these features, a user name and password are required.

Please follow these steps:

On DL.CODE, go to Device>Settings>Security Settings.

Set your password under the Web Monitor Settings tab.

NOTE: A default user name is already set, while no default password is provided for security reasons.

Open the Web Monitor by selecting it on the Task Area.

On the Web Monitor tool, open the Menu on the upper right-hand corner and select either Code Grading Monitoring or Configurator.

A pop-up window will be displayed prompting the user to enter user name and password.

Code Grading Monitoring Page

To view Code Grading live results, the user first needs to enable code grading on DL.CODE (see Chapter 13, Code Grading).

On the Code Grading Monitoring Page the user can see live results in graphs. Results can either be viewed as Grades or Values:

Each graph represents results for a code grading parameter. The graphs to display can be selected from the Settings icon:

Here the user can also set the number of samples and the refresh period (ms).

Configurator page

On the Configurator page the user can view the configuration currently running on the device and run another one by selecting it from the saved configurations, in particular:

• click on the single check to load the configuration;

• click on the double check to load the configuration and set it as the startup config- uration.

The loaded configuration will display a blue single check. The startup configuration will display a blue double check.

CHAPTER 5 DATA COLLECTION METHODS

CODE COLLECTION

Valid Operating Modes: Continuous, One Shot, Phase Mode, PackTrack

In Code Collection mode the reader can collect several codes before providing a single output result.

The number of codes to be collected is set by the Min Expected Codes and Max Expected Codes.

The type of output message sent to the host depends on the No Read and Multiple Read parameter settings and can be modified and formatted in the Data Formatting Output Group.

Example:

As shown in the figure above, the following parameters are set:

The DMECC200, CODE39 and CODE128 code types are enabled and present in the Code Collection.

Min Expected Codes = 2; Max Expected Codes = 3; No Read is Enabled; Multiple Read is Enabled

Case 1:two or three codes (of the enabled code types) are read

Output:the content of Message 1 Success is sent to the Host. This corresponds to a Good Read message and by default contains the code content.

Case 2:one code is read

Output:the content of Message 2 Failure is sent to the Host. This corresponds to the No Read message because it doesn’t satisfy the minimum expected codes criteria.

Case 3:four codes (of the enabled code types) are read

Output:the content of Message 3 Multiple Read is sent to the Host. This corresponds to the Multiple Read message because it exceeds the maximum expected codes criteria.

If the Multiple Read parameter is Disabled, then Case 3 is considered a Good Read and the content of Message 1 Success is sent to the Host containing the first three decoded codes.

In Phase Mode, by setting *Analysis* to Within Phase only the reading phase is consid- ered and a single result is provided to the user for each phase. On the other hand, by selecting Within An Image the reader searches for the defined number of codes within each acquired image and a result is provided to the user after each image decoding.

CODE COMBINATION

Valid Operating Modes: Continuous, One Shot, Phase Mode, PackTrack

In Code Combination mode the output results sent to the Host depend not only on the codes read but on meeting their configured logical combination criteria.

Example:

As shown in the figure above, the following parameters are set:

The DMECC200, QR Code and CODE128 types are enabled and present in the Code Combination with the following logical combination:

DMECC200 OR QRCode AND Code128.

No Read is Enabled; Multiple Read is Enabled; Partial Read is treated as No Read

Case 1:codes (DMECC200 AND Code128) or (QR Code AND Code128) are read

Output:the content of Message 1 Good Read is sent to the Host. This message by default contains the code content.

Case 2:only one of the three codes (DMECC200, QR Code or Code128) is read

Output:this is a Partial Read which, in this example, is treated as a No Read. The content of Message 2 No Read is sent to the Host.

Case 3:all three codes (DMECC200, QR Code and Code128) or (only DMECC200 and QR Code) are read

Output:the content of Message 3 Multiple Read is sent to the Host.

If the Multiple Read parameter is Disabled, then for Case 3:

• all three codes read (DMECC200, QR Code and Code128), is considered a Good Read and the content of Message 1 Good Read is sent to the Host containing one of the 2D codes (whichever was decoded first) AND Code128.

• reading (only DMECC200 and QR Code), is considered a Partial Read which, in this example, is treated as a No Read and the content of Message 2 No Read is sent to the Host.

In Phase Mode, by setting *Analysis* to Within Phase only the reading phase is consid- ered and a single result is provided to the user for each phase. On the other hand, by selecting Within An Image the reader searches for the defined combination of codes within each acquired image and a result is provided to the user after each image decod- ing.

NOTE: In Code Combination mode, the configured expression can contain up to a maximum of 50 codes.

CODE PRESENTATION

Valid Operating Modes: Continuous, One Shot, Phase Mode (Motion Sensor)

In Code Presentation mode typically a code is placed in front of the reader manually and the successful output results are sent to the Host. Usually No Reads are disabled and the configuration should correctly manage Multiple Reads.

Example:

As shown in the figure above, the following parameters are set:

The DMECC200, CODE128 and CODE39 types are enabled and present in the Code Pre- sentation:

No Read is Disabled; Code Filter Depth is 1, and multiple reads are handled by the Acquisition Counter Threshold: Success Threshold=0, Failure Threshold=1.

Case 1:any code or combination of codes (of the enabled code types) is read in a single acquisition.

Output:the content of Message 1 Success is sent to the Host containing one occurrence of all of the decoded codes. This message by default contains the code content.

Case 2:any code or combination of codes is presented to the reader repeatedly Output:this is a multiple read condition which is managed as follows:

Success Threshold=0, the same code (by content and type) cannot be read in successive acquisitions.

Failure Threshold=1, the same code (by content and type) can only be read after at least 1 acquisition without a code.

MATCH CODE

In Match Code mode the output results sent to the Host depend on whether the codes read meet the match code criteria or not.

User Defined

Valid Operating Modes: Continuous, One Shot, Phase Mode

Example:

As shown in the figure above, the following parameters are set: CODE39 type is enabled and present in the Match Code:

No Read is Enabled; Match Code Input is User Defined where the Expected Content = “0*” (all codes must begin with zero but can be followed by any string – wildcard).

Case 1:a CODE39 type is read and its content begins with 0 (zero).

Output:the content of Message 1 Match Code is sent to the Host. This message by default contains the code content.

Case 2:a CODE39 type is read but its content does not begin with 0 (zero). Output:the content of Message 2 No Match Code is sent to the Host.

Case 3:no CODE39 type is read.

Output:the content of Message 3 No Read is sent to the Host.

Input Based

Valid Operating Modes: One Shot, Phase Mode

The reading phase is typically controlled by Input 1 (Trigger) while Input 2 is used for Match Code saving. An alternative is to control the reading Phase by sending strings from one of the available communication Channels.

Example:

As shown in the figure above, the following parameters are set: Data Matrix ECC 200 type is enabled and present in the Match Code:

No Read is Enabled; Match Code Input is Input Based (captured by the Input 2 High state), Saved to Permanent memory with configuration job name = “Match Code from Input”.

NOTE: Capturing the Match Code on Input must be done either in Monitor or in RUN mode (disconnected from DL.CODE). You cannot capture the match code on input from the DL.CODE configuration environment.

Switch to Monitor and trigger a reading phase while Input 2 is in the High state (for this example).

The code will be read, saved in the Expected Content list and the entire job will be saved to the configuration name “Match Code from Input”.

Return to the Configuration Environment.

If you choose the Temporary Saving Option, you will need to save the job manually from the configuration environment as with all other configurations.

Case 1:a DMECC200 type is read and its content matches a code in the Expected Con- tent list.

Output:the content of Message 1 Match Code is sent to the Host. This message by default contains the code content.

Case 2:a DMECC200 type is read but its content does not match a code in the Expected Content list.

Output:the content of Message 2 No Match Code is sent to the Host.

Case 3:no DMECC200 type is read.

Output:the content of Message 3 No Read is sent to the Host.

PRESENTATION MODE

Presentation Mode is a pre-configured case of the Phase Mode Operating Mode. It uses a software Motion Sensor to constantly search for changes in the images during the Idle state. When images change (indicating motion), the reading phase is activated to auto- matically detect any codes that will be presented to the device.

Selecting this task opens DL.CODE with the following default parameter settings:

• Phase Mode Operating Mode

• Phase On and Phase Off connected to Motion Event

• Data Collection Method is Code Presentation

• Code Filter Depth is 1

• Threshold Timeout 2 sec

• Data Matrix symbology enabled.

• Output Message to the Host is sent to the TCP Channel

• Green Spot is illuminated on successful read

This default is useful for kiosk or cash register applications where a single code is pre- sented to the reader one-at-a-time by hand. The movement is typically < 0.5 m/s and the Focusing Pointer system is enabled during the Idle state to show where the code must be presented. The illuminator is off in the Idle state to avoid constant flashing. Either the code is returned or no message is returned.

Another type of application is an In-line application where packages are introduced on a relatively slow moving conveyor (< 1 m/s). Typically the Code Combination Data Collec- tion method is used. Either the codes are returned or a No Read message is returned.

The Presentation Mode can also be used with the Code Collection Data Collection method.

CHAPTER 6 PROTOCOL INDEX

OVERVIEW

Protocol Index is a feature allowing a custom message (string) sent from a remote Host to be assigned to a specific reading phase or pack. A typical application is assigning a message containing the weight, dimensions, etc., to each package passing through the system.

Protocol Index can be used either in Phase Mode (during the active reading phase) or in PackTrack operating mode (between the PS Offset and the Tx Line Distance).

Up to 10 different Protocol Indexes can be configured but each one must be transmitted over a dedicated communication channel (source). They can all transmit at the same or different assignment points.

COMMUNICATION CHANNELS
Allowed	Not allowed
Serial	Modbus TCP Client embedded
TCP Server or Client	Ethernet/IP embedded
HMS Fieldbus
Profinet-IO embedded
Modbus TCP Server embedded

Header and Terminator strings must be configured whenever a new Protocol Index object is added to a configuration. Either Header or Terminator can be blank but not both at the same time.

Typically if the Protocol Index Message Length Type is Variable Length, then both Header and Terminator will be needed.

If the Message Length Type is Fixed Length, then at least the Header or the Terminator is necessary.

NOTE: Header and Terminator must be used for protocol index whenever an input channel (e.g. TCP/UDP client server) is also used as input of other services (e.g. phase/trigger generation). This is to avoid mixing triggers and protocol index messages.

PROTOCOL INDEX

INCLUDING PROTOCOL INDEX IN THE OUTPUT MESSAGE

This message (in whole or in part), is also usually included in the output message. Each PI message can be added to the output message by including a Protocol Index Field.

It is usually good practice to add the same PI message to both the Good Read and No Read output messages.

PARSING A COMPLEX PROTOCOL INDEX MESSAGE

A single complex Protocol Index message coming from a single channel can be received from a Host and can be divided into separate Protocol Index messages in the Data For- matting output message.

For further details on the Protocol Index Message, see the parameter descriptions in the DL.CODE Help On Line Protocol Index page.

CHAPTER 7 MESSAGE FORMATTING

Message Formatting is extremely flexible to allow a high level of customization depend- ing on the application requirements. This however makes formatting more complex.

NOTE: A new Script Formatting tool based on javascript is provided to per- sonalize the output message to a higher level than what is available using the standard Output Message tools. This tool is recommended only for peo- ple experienced with scripting. For details see "Script Formatter" on page 114.

Here we will break down the main characteristics of the Output Message and describe the standard Output Message tools.

Information relative to code reading is transmitted in standard formats on the device’s selected interface. We refer to this as the OUTPUT MESSAGE. The general format of the OUTPUT MESSAGE is:

The RESULTS component is composed of several optional fields which are used in differ- ent combinations to create different output messages (like Successful Read, No Read, Statistical Data, Diagnostic Data, etc.). These fields can be inserted into the output mes- sage in any order. A list of the formatting fields is given in the table below.

FIELD LENGTH MANAGEMENT

FIELD LENGTH MANAGEMENT

All field types by default are Variable Length fields but they also support Fixed Lengths with cutting and filling mode options.

INPUT STRINGS

All Input String fields have a table icon to the right of the field which allows you to input all ASCII characters including non-printable characters.

Just single-click on the desired character to insert it into the string.

While it is quicker to type normal characters directly from your keyboard, non-printable characters must be entered using the table.

FIELD SEPARATOR

When Operating Mode is set to Code Collection or Code Presentation, the Field Separa- tor character or string is used to separate each formatted code message within the com- plete output message #n. For example:

[Header] [formatted Code1] [Field Separator] [formatted Code2] ... [Terminator] Each defined message #n can have a different Field Separator.

Example:

INDEPENDENT DIAGNOSTIC MESSAGES

As a troubleshooting tool or for error monitoring a Diagnostic Message can be sent independently from the code reading message.

For demonstration purposes, the figure below shows the Diagnostic Message for a Backup Memory Communication Failure being monitored and sent every 3 seconds on the output independently from the code reading output message.

Typically only the Failure string is defined to avoid unnecessary message traffic.

Only upon failures, the Failure Mask sends a fixed 32-character mask. Each character represents the Standalone/Master device + 31 Slaves. The ASCII mask sends 0 =OK and 1

= Failure. The Binary mask sends non-printable characters.

The mask is appended to the Failure Content message (if defined).

INDEPENDENT DIAGNOSTIC MESSAGES

This monitoring could be sent to another channel so as not to interfere with data com- munication, for example to another Matrix TCP Server connection, as shown below.

Several Diagnostic fields can be added to the Diagnostic Message for complete monitor- ing.

CODE COMBINATION MESSAGE FORMATTING EXAMPLE

In Code Combination the expected result is always known in terms of code reading.

To simplify these examples we will not consider Code Cutting or Justification, all fields are considered with the default value as Variable Length fields.

Recalling the example in "Code Combination" on page 93:

The DMECC200, QR Code and Code128 types are enabled and present in the Code Com- bination with the following logical combination:

DMECC200 OR QRCode AND Code128.

No Read is Enabled; Multiple Read is Enabled; Partial Read is treated as No Read

Click on the various field icons to add them to the Message Field Area to compose the message.

You can drag them into different positions to change the ordering of the message fields.

You can also delete them by selecting the field with the mouse (highlighted in green), and then delete it using your keyboard.

Then modify the Data Formatting parameters of each field in the parameters panel. The Data Formatting Parameters are:

Message 1 = Good Read Header String = <STX> Terminator String = <CR><LF>

CODE COMBINATION MESSAGE FORMATTING EXAMPLE

Referenced Label = Expected Code 1 Code Related Field = Code Symbology Code Related Field = Code Content

Referenced Label = Expected Code 2 Code Related Field = Code Content

Custom Field

Custom String = <Space>->Space>

Global Statistics Field

Global Info Field Type = Total Number of No Reads

Message 2 = No Read Custom Field

Custom String = <CAN>

Message 3 = Multiple Read Custom Field

Custom String = <?>

The Output Messages are:

Case 1: codes (DMECC200 AND Code128) or (QR Code AND Code128) are read Output: the content of Message 1 Good Read is sent to the Host.

SCRIPT FORMATTER

Script formatting is designed to allow the highest level of output message configuration in place of the standard Output Message tools. It is recommended only for people expe- rienced with scripting and can be enabled from the Data Formatting – General Settings branch.

The Script Formatter will now replace the Output Messages branch. It is complete with several editing tool icons to facilitate scripting within the DL.CODE GUI.

Script Formatter is based on an embedded JavaScript engine. For DL.CODE version 1.5.0 and later, the embedded JavaScript engine conforms to ECMAScript 5.0/5.1 Language Specification.

Global Objects

Inside the script engine, the script code makes it possible to access some global objects:

Callbacks

• Statistics (see "Statistics Object" on page 121) – an object to access device global reading statistics

• Diagnostics (see "Diagnostics Object" on page 122) – an object to access device diagnostic information

• Device (see "Device Object" on page 123) - an object to access device information

Function: onResult

This callback function is called every time the code analysis completes and allows for program controlled customized formatting of one or more messages based on decoding data results.

Argument	Type	Description
result	Result(see "Result Object" on page 116)	Allows access to all the decoding data
output	Output(see "Output Object" on page 120)	Allows access to all the output messages

Example:

This simple example accesses information wrapped inside the Result object to extract the content of all the decoded codes content and concatenate it into a space separated string. The generated string is then used as the output message by accessing the Output object.

function onResult(result, output) { var message = '';

result.codes.forEach(function(code) { message += code.content + ' ';

});

output.setMessage(message ? message : 'no_read');

}

Objects Reference

Result Object

Provides functions to access decoding data.

Property	Type	Description
codes	Array	The array of all the decoded Code objects (see "Code Object" on page 117).
slots	Array	The array of all the configured Slot objects ("Slot Object" on page 119). The array contains a Slot object for each Expected Code in Code Combina- tion. If the current Data Collection is not of type Code Combination, the property is set to unde- fined.
images	Array	The array of all the decoded images Image objects (see "Image Object" on page 119).
success	Boolean	This is set to true if the current result is a Good Read, Success or Match, otherwise it is set to false.
addresses	Array	The array of device addresses that decoded at least one code. Address 0 corresponds to the Master address.
readingCount	Number	The total number of decoded codes in the read- ing phase.
rejectedCodes	Number	The number of decoded codes removed from the output based on the analysis. An example is counting multiple read codes when the Multiple Read event is disabled.
imageAcquisitionTime	Number	Average time used to acquire an image (ms).
imageWaitTime	Number	Average time in which the device is busy between acquisition and decoding of an image (ms).
imageProcessingTime	Number	Average time used to decode an image (ms).
imageld	Number	The current image identifier. This is meaningful only if Analysis is Within An Image.
phaseld	Number	The current phase identifier. This is meaningful only if Reading Phase is set to Phase Mode and Analysis is Within Phase.
phaseDuration	Number	The duration of the last phase.
phaseOffDuration	Number	The duration of the last phase off period.
packId	Number	The current pack identifier. This is meaningful only if Reading Phase is set to PackTrack Mode.
dwCodes	Array	The array of all the decoded DWCODE™ objects (see "DWCode Object" on page 118).

Property	Type	Description
getProtocolIndex	String / Uint8Array	Retrieve protocol index data from the specified channel related to this result. The function returns an object with two properties: content and binaryContent. Both represent the protocol index data, the first as a printable string, the sec- ond as a Uint8Array.

Code Object

Provides access to the data of a single decoded code.

Property	Type	Description
content	String	The content of a code as a String.
center	Point	The center position of the code inside the image.
corners	Array	The four corners of the bounding box of the code as an array of Point objects (see "Point Object" on page 119).
addresses	Array	The array of device addresses that decoded this code. Address 0 corresponds to the Master address.
binaryContent	Uint8Array	The content of the code as an Uint8Array.
symbology	String	The code symbology name
aimId	String	The AIM identifier of the code symbology.
angle	Number	The code angle.
ppe	Number	The code pixels per element.
moduleSize	Number	The code module size.
decodingTime	Number	The decoding time in microseconds.
overrunTime	Number	The time in microseconds elapsed after tool timeout.
symbolSize	String	The code symbol size (if applicable).
quality	QualityMet- rics	The Quality Metrics object (see "Quality Metrics Object" on page 118) that contains all the qual- ity metrics info for the code.
imageIndex	Number	The index number of the image containing the code. This value is undefined if the code has been decoded on a slave device.
unreadableCode	Boolean	true if the code is an “unreadable code”, false it not.

DWCode Object

Provides access to the data of a single decoded DWCODE™.

Property	Type	Description
payloadRaw	String	The raw content of the code as String.
payloadCompatible	String	The compatible content of the code as String.
payloadEnhanced	String	The enhanced content of the code as String.
payloadNative	String	The native content of the code as String.
parsedContent	Object	If possible, a map with GS1 Als and their con- tents.
unreadableCode	Boolean	true if the code is an “unreadable code”, false it not.

Quality Metrics Object

Provides access to the quality metrics of a single decoded code. Each metric returns an object with two properties:

• grade - a string representing the quality grade (A, B, C, etc.)

• value - a numeric representation of the quality

• decimalGrade - the quality grade represented as a number between 0.00 and

4.00. Note that printing this number may result in a number with many decimal digits. Use decimalGrade.toFixed(2) to limit them.

Property	Type	Description
overall	Object	Overall quality grade.
decode	Object	Decode grade and value.
contrast	Object	Contrast grade and value.
modulation	Object	Modulation grade and value.
decodability	Object	Decodability grade and value.
meanEdgeContrast	Object	Mean Edge Contrast grade and value.
axialNonUniformity	Object	Axial Non Uniformity grade and value.
uec	Object	Unused Error Correction grade and value.
printGrowth	Object	Print Growth grade and value.
minReflectance	Object	Minimum Reflectance grade and value.
defects	Object	Defects grade and value.
fixedPatternDamage	Object	Fixed Pattern Damage grade and value.
gridNonUniformity	Object	Grid Non Uniformity grade and value.
reflectanceMargin	Object	ISO/IEC 15416:2016 Reflectance Margin (only value, grade is undefined).
quietZone	Object	Quiet Zone metric (value and decimalGrade are the same).

Point Object

This is an object with the x and y pixel coordinates of a point on an image. Values are rel- ative to the upper left corner of the image (0,0).

Property	Type	Description
x	Number	The x coordinate (increases from left to right).
y	Number	The y coordinate (increases from top to bottom).

Slot Object

A slot corresponds to a single Expected Code in Code Combination. This object provides functions to access the Code objects (see "Code Object" on page 117) associated with the Expected Code.

Property	Type	Description
codes	Array	The array of all the Code objects assigned to this slot.
dwCodes	Array	The array of all the DWCODE™ objects (see "DWCode Object" on page 118) assigned to this slot.

Image Object

Provides access to the data of a single decoded image.

Property	Type	Description
acquisitionTime	Number	The acquisition time in microseconds.
waitTime	Number	The time in microseconds elapsed between end of acquisition and start of decoding.
processingTime	Number	The decoding time in microseconds.
imageld	Number	The current image identifier.

Output Object

Provides a function to set the output message to be sent to the output channel(s).

Property	Type	Description
setMessage	string,channel_id (optional)	Sets the output message. If no channel_id is specified, the message is sent to all connected channels, otherwise it is sent only to the speci- fied channel (which has to be connected to the script message in any case). At the end of the formatting script execution, for each channel, the system sends its specific message, if it exists, otherwise it sends out the generic mes- sage.
setEvent1	none	Sets Script Event 1. If called, the event will be generated at the end of the script execution. From the Output Setup group, the event can be linked to any available output.
setEvent2	none	Sets Script Event 2. If called, the event will be generated at the end of the script execution. From the Output Setup group, the event can be linked to any available output.
setEvent3	none	Sets Script Event 3. If called, the event will be generated at the end of the script execution. From the Output Setup group, the event can be linked to any available output.
setFtpFileName	string,ftp_channel_id (optional)	Sets the name of the file where the FTP chan- nel should save the content of the output mes- sage. If no ftp_channel is specified, the file name is used for all connected FTP channels, otherwise it is only used by the specified chan- nel. If no file name is specified, the default “Unknown.tmp” file name is used.
saveImages	Array of Numbers	Specifies image IDs to save. This function makes it possible to specify the images to save.
List of Numbers separated by commas
Array of Objects with id and file- name properties	Specifies image IDs to save. In addition to IDs, it is possible to specify the image filenames.
List of Objects with id and file- name properties separated by commas

NOTE: To use the save Images function, the Image Saving Controlled by Script parameter must be enabled under Image Saving Conditions.

Statistics Object

Provides access to global device statistics.

Property	Type	Description
phases	Number	Number of Reading Phases.
goodReads	Number	Number of Good Reads.
noReads	Number	Number of No Reads.
multipleReads	Number	Number of Multiple Reads.
partialReads	Number	Number of Partial Reads.
phaseOverrun	Number	Number of Phase Overruns.
triggerOverrun	Number	Number of Trigger Overruns.
unexpectedPhaseOn	Number	Number of Unexpected Phase Ons.
images	Number	Number of Image Acquisitions.
fps	Number	Current frames per second.

This object provides the following functions:

Function	Type	Description
resetStatistics	none	Reset all statistics counter.

Diagnostics Object

Provides access to global device diagnostics. Each diagnostic returns an object with the following properties:

• alarm – a flag set to true if the alarm is currently active, otherwise it is set to false.

• addresses – an array of numbers where every number is the address of the device that has activated the alarm. If the alarm equals false, the array is empty. Address 0 corresponds to the Master address.

Property	Type	Description
slaveNoReply	Object	Slave No Reply diagnostic alarm.
slaveAddressDuplication	Object	Slave Address Duplication diagnostic alarm.
fieldbusCommunicationFailure	Object	Fieldbus Communication Failure diagnostic alarm.
fieldbusDHCPFailure	Object	Fieldbus DHCP Failure diagnostic alarm.
fieldbusConfigurationFailure	Object	Fieldbus Configuration Failure diag- nostic alarm.
fieldbusTypeMismatch	Object	Fieldbus Type Mismatch diagnostic alarm.
wrongRotarySwitch	Object	Wrong Rotary Switch diagnostic alarm.
backupMemoryCommunicationFailure	Object	Backup Memory Communication Failure diagnostic alarm.
xrfSlaveNotDetected	Object	XRF Slave Not Detected diagnostic alarm.
protocolIndexFailure	Object	Protocol Index Failure diagnostic alarm.
sc5000CommunicationFailure	Object	SC5000 Communication Failure diagnostic alarm.
sc5000PresentationMessageRespon- seFailure	Object	SC5000 Presentation Message Response Failure diagnostic alarm.
noCameraHeadFailure	Object	No Camera Head Failure diagnostic alarm.

Device Object

Provides access to global device information.

Property	Type	Description
model	string	The complete model name of the device.
serial	string	The serial number of the device.
order	string	The order number of the device.
temperatures	Object	An object that stores the available temperatures of the device (Properties: sensor, motherboard, illuminator_driver, illuminator_leds, liq- uid_lens). Each property is a Number (the tem- perature) or undefined if no sensor is available on that specific device.
accelerations	Acceleration Object	All information from 3-axis accelerator, if avail- able (if not, undefined)
operatingHours	integer	The number of operating hours of the device, if available (if not, undefined)
systemStarts	integer	The number of system starts, if available (if not, undefined)
systemReboots	integer	The number of system reboots, if available (if not, undefined)
applicationStarts	integer	The number of application starts, if available (if not, undefined)
applicationFailures	integer	The number of application failures, if available (if not, undefined)
readInput	name	Returns the named input line current value as integer (0/1). Names are “Input1”, “Input2”, and so on.
readOutput	name	Returns the named ouput line current value as integer (0/1). Names are “Output1”, “Output2”, and so on.

Acceleration Object

Provides access to acceleration data.

Property	Type	Description
raw	Array of 3 integers	The raw values form 3-axis accelerometer (X, Y, and Z)
forces	Array of 3 integers	The values of G forces (X, Y, and Z) in g
tilt	Array of 3 integers	The 3 components (X, Y, and Z) of the tilt angle
roll	Number	The roll angle
pitch	Number	The pitch angle

Adjustable parameters via HMP

The Script Formatter allows the user to define a set of parameters accessible in read and write from HMP with special commands. These parameters must be declared inside the Global Parameters object: this global object is always defined but it is an empty object by default. Via HMP it is possible to add/set/get properties inside the Parameters object.

NOTE: These script parameters are never stored in permanent memory!

Add/Set Parameters property

To add or set a property of the Parameters object via HMP, use the command SCRIPT_SET_PARAM.

> Command: SCRIPT_SET_PARAM<space><property_name><space><json_string><LF>

> Positive response: ACK<LF>

> Negative response: NACK<LF>

For example, suppose to have a script like this:

// Init a property inside the Parameters object to empty string. Parameters.hmp_data = "";

function onResult(result, output) {

// set the output message to the current value of Parameters.hmp_data output.setMessage(Parameters.hmp_data);

}

It is possible to change the output message with the HMP command:

SCRIPT_SET_PARAM hmp_data "next mesage content"<LF>

Get Parameters property

To get the value of a property of the Parameters obejct via HMP, use the command SCRIPT_GET_PARAM.

> Command: SCRIPT_GET_PARAM<space><property_name><LF>

> Positive response: ACK<json_string><LF>

> Negative response: NACK<LF>

For example, considering the previous example script, it is possible to get the current value of the hmp_data parameter with the HMP command:

SCRIPT_GET_PARAM hmp_data

Script Event Digital Output Control

As well as the output message configuration, the script can also contain Output object functions that can drive the reader’s outputs.

CHAPTER 8 MONITOR

The Monitor feature is designed to check device operation from a remote PC even simultaneously with other monitoring PCs.

It can be used during installation or troubleshooting to check the device operation. The device operates with a minimum of DL.CODE overhead and therefore reading results are much closer to real-time performance.

Monitor also provides diagnostic alarm feedback.

ACCESSING THE MONITOR

You can access the Monitor page through the File menu or the Monitor icon.

MONITORING STATISTICS

The Monitor loads with the reader in run mode. If the device is reading (in Continuous operating mode or One Shot/Phase Mode with trigger active), the reader will show image acquisition. The Results area underneath the image gives feedback on decoding results.

The Statistics page is collapsed to the left side of the DL.CODE window and can be opened by clicking on its tab.

You can resize the various windows by dragging the edges with the mouse.

You can toggle between table view and chart view statistics by clicking on the icon.

You can also switch between Session and Absolute statistics.

• Session Statistics: show only the fields selected that are represented as a percent- age, rate, or average (i.e. Good Read, Partial Read, No Read, Average Pack Size, etc.) and refer to the last session or the last time the Statistics were reset up to the maximum Session number of reading phases. See below. A session ends if the device is connected to the DL.CODE configuration environment.

• Absolute Statistics: show all the fields selected in the Device menu > Settings > Configuration Settings > Statistics > Enabled Counters list from the last device power on or the last time the Statistics were reset.

Statistics Settings

From the Device menu > Settings > Configuration Settings you can set the number of reading phases to monitor for a Session (from 10 to 1000).

You can also choose which fields to visualize in the Monitor Statistics page.

The counters that can be enabled include:

• Elapsed Time (sec): the time elapsed from the start of image acquisition.

• Phase On Count: this counts all Phase On commands sent to the device.

• Pack Count: this counts all packs and parcels in systems where these are present in the reading area.

• Valid Code Count: this counts all valid codes decoded by the reader.

• Reading Phase Count: this counts all completed analyses (e.g. each phase in Phase mode or each image in Continuous mode).

• Trigger Overrun Count: this increases every time a trigger is ignored. This happens when the device cannot acquire an image when the trigger is received. Please note that in Monitor mode the device ignores more triggers than what normally happens.

• Number of Decoded Codes: this counts all codes that the reader has successfully decoded.

• Encoder Errors Count: this counts the errors reported by the encoder.

• Number of Spurious Phases: a “spurious phase” can occur at the end of an acqui- sition. When the phase is closed by one of the available events, this counter value is incremented if no image was acquired during the phase active time.

• Unreadable Code Counter: this counts all codes that the reader was not able to completely decode (only available for Code 39, Code 128, and Interleaved 2 of 5 symbologies). Note that only one unreadable code per frame can be detected.

• Good Read Count: the percentage of successfully decoded codes in the total of analyzed codes.

• Partial Read Count: this counts the analyses that resulted in a Partial Read.

• No Read Count: this counts the analyses that resulted in a No Read.

• Multiple Read Count: this counts the analyses that resulted in a a Multiple Read.

• Successful Collection Count: this counts the analyses that resulted in a Successful Collection.

• Failed Collection Count: this counts the analyses that resulted in a Failed Collec- tion.

• Match Code Count: this counts the analyses that resulted in a Match Code.

• No Match Code Count: this counts the analyses that resulted in a No Match Code.

• Phase Overrun Count: a Phase Overrun event can occur when the reader is work- ing in Phase Mode and a “phase open” event is overrun by a subsequent “phase open” event. If current logical phase has not been completely processed but all the expected images for the phase interval have been captured, images are still being processed and decoding results are not yet available, transmission point has not been reached, or phase timeout has not yet expired (i.e.: the phase is still “open”). Any additional “phase open” events received in this period will result in the closure of the current phase with any processing results collected so far being committed and dispatched. A New phase acquisition process is started. This condi- tion should not be considered as an “error” and may instead occur naturally during normal operating conditions. This statistics counter is for registration pur- poses only.

• Unexpected Phase On Count: an Unexpected Phase On event occurs when the reader is working in Phase Mode and a “phase open” event is overrun by a subse- quent “phase open” event. If the reader is still acquiring images, the phase pro- cessing is not affected by the event and operations continue as if the event was not received. This statistics counter is for registration purposes only.

• Valid Packs: this counts valid packs and parcels in PackTrack mode.

• Pack Too Short: this counts the events of “Pack too short”. According to the Pack- Track configuration, these can be ignored or cause the pack to be discarded.

• Pack Too Close: this counts the events of “Pack too close”. According to the Pack- Track configuration, these can be ignored or cause the pack to be discarded.

• Pack Too Long: this counts the events of “Pack too long”. According to the Pack- Track configuration, these can be ignored or cause the pack to be discarded.

• Average Pack Size (mm): this measures the average size of packs in parcels.

• Average Pack Distance (mm): this measures the average distance between packs.

• Already Transmitted Parcel’s Codes: in PackTrack mode, this counter value is incremented when a label has been decoded after the pack it should be assigned to has already hit the transmission point. The label is discarded.

• Discarded Codes: this counts all codes that are discarded and not decoded (e.g. codes exceeding the maximum number of characters set by the user).

• Codes in Parcel: in PackTrack mode, this counter value is incremented when a decoded label is successfully assigned to a pack in the tracking area.

• Codes Out of Parcel: in PackTrack mode, this indicates that a label has been suc- cessfully decoded but could not be assigned to a specific parcel currently in the tracking area.

• Frame Rate: this indicates the device acquisition frame rate.

• Conveyor speed (mm/s): this indicates the conveyor speed in mm/s.

• Encoder Frequency (Hz): this indicates the frequency (Hz) of the encoders used in the application.

• Filtered Codes Count: this counts all filtered codes.

• Average Codes or Labels Found: this indicates the average number of codes or labels found in each completed analysis.

• Average Decoding Time (ms): this indicates the average time (ms) needed to decode all analyzed codes.

• Image Acquisition Counter: this counts the images acquired by the device.

• Received Protocol Index: this counts the Protocol Index messages received by the device.

• Protocol Index Errors: when using Protocol Index, this counter value is incre- mented when a parcel is assigned multiple protocol indexes by the host system.

• Good Protocol Index: when using Protocol Index, this counter value is incre- mented when a parcel is assigned one single protocol index by the host system.

• Code Overrun Counter: this indicates that a Code Overrun condition1 has been detected.

• Average Code Overrun: Code Overrun condition1 time is internally registered and the average value is continuously updated and reported in milliseconds (only Code Overrun conditions since the last Statistics Reset are considered).

• Average Image Acquisition Time: this indicates the average time (ms) needed for image acquisition.

• Average Image Processing Time: this indicates the average time (ms) needed to process an image.

• Image Lost Counter: when using Image Saving, references to acquired images are stored into an internal queue as long as they are needed for processing purpose. When an entry in the queue is invalidated by some processing condition (image rate, queue management policy, etc.), this counter value is incremented and the corresponding image is not saved in the predefined destination.

• Image Tx Failure Counter: this counts the number of image transmission failures.

A Code Overrun condition occurs when a decoded label can be reported to client modules between a “stop decoding” command sent to the decoding module and its corresponding acknowledge reply.

You can reset all the statistics (both Session and Absolute) clicking on the Reset Statistics icon or by selecting the Reset Statistics command from the Device menu > Settings.

MONITORING DIAGNOSTIC ALARMS

Any Diagnostic Alarms will show up as a warning light on the alarm panel. Most Alarms are relative only to Standalone or Master readers.

Alarm Code	Description	Meaning	Action
1	Slave No Reply	No response to master from slave (shown in slave column).	Check that the Slave device is pow- ered on.Check that the Slave device is con- nected to the network.Check that the Slave device is ready.
64	Slave Address Duplication	Two or more slaves have the same address.	Change network configuration to remove Slave address duplication.
93	Focus Motor Failure	The focus motor is not working prop- erly.	Cycle power to the device. If the issue persists, contact Datalogic Repair Center.
100	Image Saving Tx Failure	This failure is triggered in case of communication problems with the server.	The failure root cause could be due to the server or the network. For exam- ple:• Server unavailability or failure• Unavailability or failure of the net- work infrastructure• Full disk on the server• Antivirus not properly configured• Firewall issues, especially in pas- sive mode (e.g. firewall blocks file transfer ports).

MONITORING DIAGNOSTIC ALARMS

Alarm Code	Description	Meaning	Action
124	High Tempera- ture Warning	The device temperature is approach- ing the maximum allowable tempera- ture.	Check that the device is properly mounted on a metal bracket and the environmental temperature does not exceed the device max. allowable temperature. If the issue persists, contact Datalogic Technical Support.
171	Protocol Index Failure	The expected Protocol Index is not received. This alarm is activated when:• three or more consecutive packs/ phases have no protocol index attached;• five or more packs/phases with no protocol index attached occur with a window of 100 packs/phases.When more than one configured Pro- tocol Index is configured, the alarm condition is active whenever one of the errors above is true.	Check that the system providing the Protocol Index information is alive and the Protocol Index information is provided within the configured tim- ing.
185	Backup Memory Communication Failure	There is a communication error between the reader and the external memory (BM100 module inside the CBX connection box or QLM Gate- way).	Check that the BM100 module is cor- rectly installed inside the CBX100/ 500.
187	Wrong Rotary Switch Selection	One or more of the selected BM100 Rotary Switch settings inside the CBX doesn't match the reader configura- tion memory.	Adjust the rotary switch or change the reader configuration.
189	Fieldbus Communication Failure	There is a communication error between the reader and the Fieldbus module inside the CBX connection box or QLM Gateway.	Check that the Fieldbus module is correctly installed inside the CBX500. Check that it is powered on (LEDs blinking at startup).
191	Fieldbus Type Mismatch	The Fieldbus module inside the CBX doesn't match the one saved in the reader configuration memory.	Adjust the reader configuration.
193	Fieldbus Con- figuration Error	A configuration error has occurred between the reader and the Fieldbus module inside the CBX connection box.	Adjust the reader configuration.
195	Fieldbus DHCP Problem	A communication problem has occurred between the DHCP server and the Fieldbus module inside the CBX connection box or QLM Gateway.	Check that the DHCP server is alive and correctly configured to provide an IP address to the module (e.g. MAC list of allowed devices).
197	Low Tempera- ture Warning	The device temperature is approach- ing the minimum allowable tempera- ture.	Check that the device is properly mounted on a metal bracket and the environmental temperature does not fall below the device min. allowable temperature. If the issue persists, contact Datalogic Technical Support.

Alarm Code	Description	Meaning	Action
201	No XRF Slave(s) Detected	The XRF Master must have at least one XRF Slave.	Check power and ID-NET connections between Master and Slave units.
301	SC5000Communication Failure	There is a communication error between the reader and the SC5000 Controller.	Check that the connection cables are plugged in correctly. Check that the SC5000 controller is alive.
302	SC5000Presentation Messagge Response Failure	There is a configuration error between the reader and the SC5000 Controller.	Adjust the system configuration to fix the error. This kind of typically caused by the TX Line position or start posi- tion (address).
310	Excessive Bumps Warning	The device is detecting mechanical shocks of an intensity greater than 10G.	Check that the frame where the device is mounted is not subjected to mechanical shocks.
311	Orientation Change Warn- ing	The orientation sensor detects a position change of the reader greater than 2 degrees compared to the Pitch and Roll reference parameters.	Restore the original device orienta- tion or change the reference orienta- tion.
1000	Real Time Clock Failure	Invalid Real Time Clock date/time.	Contact Datalogic Repair Center.
1001	Network Time Protocol Failure	Network Time Protocol is not syn- chronized and will be checked every two seconds until it is synchronized.	Make sure the NTP server is alive and correctly configured in the reader configuration.
999900	System Failure	Very severe failure on hardware sys- tem initialization.	Cycle power to the device. If the issue persists, contact Datalogic Repair Center.
999901	Video Sensor Failure	Failure on video sensor initialization.	Cycle power to the device. If the issue persists, contact Datalogic Repair Center.
999902	Illuminator Fail- ure	Failure on illuminator initialization.	Cycle power to the device. If the issue persists, contact Datalogic Repair Center.
999903	Liquid Lens Failure	Failure on liquid lens initialization.	Cycle power to the device. If the issue persists, contact Datalogic Repair Center.
999904	I/O Failure	Failure on input/output or serial ports initialization.	Cycle power to the device. If the issue persists, contact Datalogic Repair Center.
999905	Thermal Sen- sor Failure	Failure on thermal sensor initializa- tion.	Cycle power to the device. If the issue persists, contact Datalogic Repair Center.
999906	Generic Failure	Minor failure on system startup.	Cycle power to the device. If the issue persists, contact Datalogic Repair Center.
999998	Camera Head Failure	There is a communication error between the reader and its internal camera module.	Cycle power to the device. If the issue persists, contact Datalogic Repair Center.

MONITOR SETTINGS

Several options can be set for the Monitor window. They are set in the Options>UI Set- tings menu on the Monitor tab.

Monitor Images Options

The Monitor Images Options tab includes the following settings:

• Enable Image and Results Transfer: enables the image feedback in the Monitor win- dow.

• Display ROI on Image: shows the bounding box around each code on the image.

• Display Phase on Image: shows the Phase identification number in white letters over the upper left-hand side of the image.

• Display Image Resolution: shows the Image resolution in white letters over the upper left-hand side of the image.

• Image Scaling Factor: allows downsizing the image subsampling to increase the visualization performance.

View Window

The View Window tab includes the fol- lowing settings:

• Console: shows the Console panel to view output messages.

• Configuration: shows the Configu- ration panel to allow viewing the configuration parameters (read- only).

Configuration cannot be per- formed from the Monitor window.

• Enable Statistics/Diagnostics Refresh: if enabled, the Statistics/Diagnostics counter is refreshed at a set rate.

• Statistics/Diagnostics Refresh Rate (ms): sets the rate at which the Statistics/ Diagnostics counter is refreshed.

• Automatically start Run Mode in Monitor: when launching Monitor the window opens with the device in Run Mode. This is the default setting.

CHAPTER 9 IMAGE SAVING

DEVICE IMAGE BUFFER

The Device Image Buffer allows saving captured images to the internal device memory (RAM) for data collection analysis. These images can be sent to a remote or local PC, an FTP server, or an SFTP server at run time; or they can be downloaded from the buffer when the device is offline (not in run mode).

CAUTION: The internal device memory has a circular buffer to avoid overrunning the available memory. To save images correctly to the internal buffer, you need to calculate the number of images the buffer can hold based on the image resolution for your device model. More images can be stored in memory by scaling down the image size.

This does not apply to Matrix 120 devices**,** which can save up to 2 images to the internal buffer.

NOTE: Transferring images remotely may slightly reduce the decoding rate. It is recommended to use this feature only when enough time is available to guarantee the decoding of all images**.**

Image Saving Conditions

Maximum Depth sets the total number of images that can be sent from or saved to the Device Image Buffer. Set this figure to a practical value taking into consideration the above mentioned CAUTION.

Scaling Factor allows reducing the size of images to be saved so that a greater number of images can be saved in the Device Image Buffer.

Pixel Subsampling reduces the image dimensions by subsampling the original image. The saved image will have 1 pixel every X pixel of the original image, where X is the parameter value, as reported in the table below.

SUBSAMPLING VALUE	SAVED IMAGE WIDTH AND HEIGHT RESPECT TO THE ORIGINAL IMAGE	SAVED IMAGE SIZE IN PIXEL RESPECT TO THE ORIGINAL IMAGE
1 (default)	Same	Same
2	1/2	1/4
3	1/3	1/9
4	1/4	1/16
5	1/5	1/25
6	1/6	1/36
7	1/7	1/49
8	1/8	1/64

When width and height are not perfectly divisible by the pixel subsampling, they are rounded down (e.g. 100/3 = 33).

In case of image cropping, subsampling works on the cropped image.

Image Saving Using Matrix TCP Server/Client

To add an image saving condition to the configuration, click on the Add Image Saving Condition icon.

When selecting a Remote Image Destination, the default value is Send Image From Matrix TCP Server (on-board Ethernet) channel to an external TCP Client. If desired, a different dedicated Matrix channel can be added for image transfer.

NOTE: In Phase Mode, when only one communication socket is used to send Phase On and Phase Off commands as well as receive result strings sent by the device, the device might stop responding if the Client application does not process all sent data.

According to the selected Saving Condition parameter, after data collection analysis is complete, images can be sent at run time directly from the Device Image Buffer to a remote or local PC.

The Image Saving format is:

[Header] [Image Buffer] [Terminator]

The Image Buffer contains the image data in the selected format (.bmp, .jpg,

.png, .tif).

If the RAW data format is selected, the Image Buffer data is preceded by 8 bytes which indicate the image size: the first 4 bytes indicate the image columns (width) while the last 4 bytes indicate the image lines (height) in little-endian ordering.

Image Saving Using Matrix FTP Client

Images can be sent at run time directly from the device image buffer to an external FTP Server through a Matrix FTP Client channel. The Matrix FTP Client must be added as a new communication channel since it is disabled by default. Do this by selecting the channel icon.

• The Server Address must match the external FTP Server PC.

• The Username and Password must match the ones required by the external FTP Server PC.

Now select Images Saving and set the Send Image From parameter to Matrix FTP Client.

Input the name of the Remote Folder on the FTP Server to which the image files must be saved.

NOTE: Some FTP Clients allow reducing the speed limit of image transfer- ring. However, it is not advisable to set a speed limit below 4069 KB/s.

Image Saving Using Matrix SFTP Client

NOTE: Currently this feature is only available on Matrix 220 reader.

Images can be sent at run time directly from the device image buffer to an external SFTP Server through a Matrix SFTP Client channel. The Matrix SFTP Client must be added as a new communication channel since it is disabled by default. Do this by selecting the channel icon.

• The Remote Address must match the external SFTP Server PC.

• The available authentication methods are Username/Password and Public Key:

-The Username and Password must match the ones required by the external SFTP Server PC.

-The Public Key must be set by uploading a .crt or .pub file from the local PC.

Now select Images Saving and set the Send Image From parameter to Matrix SFTP Cli- ent.

Input the name of the Remote Folder on the SFTP Server to which the image files must be saved.

Image Saving On Demand to WebSentinel FTP Server

Images can be sent to the WebSentinel FTP Server through a Matrix FTP Client channel upon receiving a Download command from Datalogic WebSentinel™ through the Down- load buttons in the Event Search tab. See the description in the Datalogic WebSentinal User's Manual.

This selection applies only to One Shot and Phase Mode Operating Modes.

NOTE: In order for Datalogic WebSentinel to communicate with the Matrix array you must enable WebSentinel Monitor Status in the 145 Device>Set- tings>Configuration Settings menu.

The Matrix FTP Client must be added as a new communication channel since it is dis- abled by default. Do this by selecting the channel icon.

• The Server Address must match the external WebSentinel FTP Server PC.

• The Username and Password must match the ones required by the external Web- Sentinel FTP Server PC. For WebSentinel the defaults are anonymous, anony- mous.

Now select Images Saving and set Send Image On to Demand and set the Send Image From parameter to Matrix FTP Client.

Input the name of the Remote Folder on the FTP Server to which the image files must be saved.

Image Saving On Demand Using Send Images HMP Command

Images can also be sent to a remote destination through a Matrix communication chan- nel (typically to an FTP Server through a Matrix FTP Client channel), upon receiving a Send Images command from the Host. See the Matrix N Family Host Mode Program- ming manual for details on this command.

This selection applies only to One Shot and Phase Mode Operating Modes.

Image Saving Using Internal Buffer

Images can be saved to the Device Image Buffer and be downloaded to a PC when the device is offline.

To download the saved images, the device must be in offline mode. Through the Device menu>RAM Image Buffer you can access the Image Buffer Management window.

UI IMAGE BUFFER

Upon opening this window, the images in the Device Image Buffer (RAM) are transferred to the DL.CODE Device Image Buffer Management window and the images are deleted from the device RAM.

You can save all the images in a zip file to the PC or you can delete the images from the DL.CODE Image Buffer Management memory.

UI IMAGE BUFFER

The UI Image Buffer manages the images captured through the DL.CODE Play and Cap- ture features.

CHAPTER 10 MULTI DEVICE CONFIGURATION OPTIONS

NOTE: DL.CODE now supports several different multi device configuration types using the PASS-THROUGH configuration. In particular this feature allows MULTIDATA ID-NET network configurations to be made. Master/ Slave SYNCHRONIZED ID-NET network configurations are also configurable as before.

PASS-THROUGH CONFIGURATIONS

Starting from software version 1.3.0, DL.CODE and Matrix N family readers support pass-through multi device configurations.

PASS-THROUGH CONFIGURATIONS

The pass-through configuration allows individually working devices (Alone), to collect data from other devices (also working Alone), and pass this data to a third device through a different communication channel. See the figure below as an example.

Aux Serial Interface (RS232) Pass-through Input channel Output channel

Figure 17 - Example Pass-through Layout

The following screenshots show the configuration settings for the three devices in the example above.

INTERNAL NETWORK CONFIGURATIONS

Internal Network configurations (also called Master/Slave configurations), are designed to collect data from several devices connected together in an ID-NET™ network and send data output to the Host system.

DL.CODE has a Net Autoset feature for the Internal ID-NET Network which automatically recognizes and assigns addresses to all connected Slave readers.

In order to automatically recognize the ID-NET Slaves, all devices must be physically installed and electrically connected (including ID-NET network wiring).

The general procedure is to:

Mount all the readers (mechanical and electrical installation) with factory default settings (Layout Type = Alone, Internal Network Role = Slave).

Connect to the designated Master device in DL.CODE and open the Setup Internal Network Configuration. You will be prompted to change the device to Master. Click OK. The Slave units will automatically be recognized.

Depending on the application, select Multidata, Synchronized Phase Mode or Syn- chronized PackTrack Configuration.

Master Configuration

First start with the desired device to assign as ID-NET Master (current default setting is Slave). Click on Setup Internal Network Configuration from the Task area.

You will be advised that the device role will be changed to Master.

Click OK. The Net Autoset feature automatically starts to find Slave devices connected to the ID-NET network of the Master.

When finished, all the Slaves should have been correctly recognized. If not, verify all device connections and power and then repeat the operation by clicking on the Start Net Autoset button.

Slave Reorder and Wink Check Procedure

Slave devices connected to a Master device in an ID-NET network can be ordered as needed. From the Setup Internal Network Configuration window, click on the Set Slaves Order button.

NOTE: This feature is only available for Online Devices**.**

The following window opens:

Click on the up and down arrows next to each Slave device to set their order within the cluster (network address).

Clicking on the Test button all devices will wink in the new set order, starting from the Master device.

Click OK to confirm the new network addresses of the Slave devices.

The OK and Test buttons will be dis- abled if the network addresses of each Slave device are not unique (range 1-31).

Internal Network Icons

NOTE: The internal network can be pre-configured by right-clicking (and waiting), on the “add a Device” button under the last slave. Placeholder slave device(s) will be added to the list and a new slave network address for each will be assigned to them. When a device is physically revealed, through the Start Net Autoset button, it will be associated with the first placeholder in the list.

While the entire internal network can be pre-configured, each device must be physically added to the network one-at-a-time in order to be correctly recognized by the network.

Depending on the application, select one of the Default Internal Network Configura- tions: Multidata, Synchronized Phase Mode or Synchronized PackTrack.

This selection will open a pre-configured job for the Master reader according to the selection. Follow the specific application instructions in the following paragraphs.

Multidata ID-NET Network Configurations

The Multidata ID-NET network communications between Master and Slave are man- aged by the application job (configuration) using the pass-through feature. A pre-config- ured job is loaded with the correct pass-through settings for both the Master and Slaves when the Default Multidata Configuration is selected from the Internal Network Setting feature.

Complete the configuration of all the application parameters (including Image Set- tings) and save them to the Master with an application specific name. Optionally, checking the Save on Slave Device box can be helpful to save all the current indi- vidual Slave configurations with the new configuration name. This does not clone any parameters. If not checked, Slave configurations will remain as Temp configu- rations and you will be warned that changes to the Master have not been saved to the Cluster. For Multidata configurations, the option to Clone Master configura- tion on Slaves must not be checked.

Figure 18 - Saving Multidata Configuration to Master

The jobs must not be cloned because the Master and Slaves have different input/output communication channels. The readers are also working independently from each other, often on separate stations with different code reading requirements, different operating modes, etc.

Connect to each Slave reader via Ethernet (see note below), and set all the config- uration parameters of each Slave device.

NOTE: If necessary, Slave device photometric (Image Settings) parameters must be configured separately through DL.CODE. This is preferably done through each device’s Ethernet TCP/IP channel. If Slave devices are not connected to Ethernet you must temporarily (manually) connect them one by one to perform Image Settings.

Open the Slave specific application job, (it will either have the new name saved from the Master or Temp depending on the Save on Slave Device selection).

When the configuration opens, pause run mode and set all the application specific con- figuration parameters (including Image Settings).

Verify the focus and decoding with the capture image function.

Now save them to a new Slave specific application job name1.

Figure 19 - Saving Multidata Configuration to Slave 1

Repeat this procedure for each Slave device until the entire network is configured.

If Save on Slave Device was selected when saving the Master configuration, an application job with the same name (but with all Slave specific configuration parameters), has been saved to the Slaves. No parameters have been cloned from the Master. There are no common param- eters managed by the Master for Multidata configurations.

Example Multidata ID-NET Configuration

The Multidata ID-NET network takes advantage of the pass-through configuration to allow all the connected readers to work independently from each other (Layout Type = Alone).

In this way data is collected over the ID-NET network and passed–through the Master to the Host system on a different communication channel. See the figure below as an example.

Main Serial Interface (RS232 or RS422 Full-Duplex) Aux Serial Interface (RS232)

Pass-through Input channel Output channel

Figure 20 - ID-NET Multidata (Pass-through)

The following screenshots show the pass-through configuration settings for the three devices in the example above.

Synchronized ID-NET Network Configurations

The Synchronized ID-NET network communications between Master and Slave are inter- nally managed by the application software. A pre-configured job is loaded with the Syn- chronized Layout Type and the correct Operating Mode for both the Master and Slaves when either the Phase Mode or PackTrack Configuration is selected from the Internal Network Setting feature.

Complete the configuration of all the application parameters (including Image Set- tings) and save them to the Master with an application relative name and with the option to Clone Master configuration on Slaves.

Figure 21 - Saving Synchronized Phase Mode Configuration to Master

Connect to each Slave reader via Ethernet (see note below), and set the Slave spe- cific parameters.

NOTE: If necessary, Slave device photometric (Image Settings) parameters must be configured separately through DL.CODE. This is preferably done through each device’s Ethernet TCP/IP channel. If Slave devices are not connected to Ethernet you must temporarily (manually) connect them one by one to configure Image Settings.

Open the cloned application job.

When the job opens, pause run mode and configure the Slave specific parameters. These depend on the application and include the following:

• photometric parameters (Image Auto-Setup feature in the Manual Setup - Image Settings step)

• Acquisition Trigger Delays necessary to avoid lighting interference between adja- cent or oppositely positioned readers (Reading Phase step)

• Images Saving if used (Data Formatting step)

• Encoder Sensor: if used, (for all Slaves, the Encoder Type must be set to Internal)

Verify the focus and decoding with the capture image function.

Now save them overwriting the cloned application job1.

Figure 22 - Saving Synchronized Phase Mode Configuration to Slave

Repeat this procedure for each Slave device until the entire network is configured.

An application job with the same name as the Master’s has been cloned to the Slaves. Each Slave can have its own Image Settings parameters saved in its own copy of the application job. Common parameters managed by the Master such as Operating Mode cannot be modified in the Slave jobs and are shown in dark gray.

Example Synchronized ID-NET Configuration

When the device is working in a Synchronized Layout Type, the ID-NET connection is used to collect data from several readers to build a multi-point or a multi-sided reading system; there can be one Master and up to 31 Slaves connected together.

The Slave readers are connected together using the ID-NET interface. Every slave reader must have an ID-NET address in the range 1-31.

The Master reader is also connected to the Host on one of its communication channels. In the following example the TCP/IP on-board Ethernet interface is used.

For a Master/Slave Synchronized layout the External Trigger signal is unique to the sys- tem; there is a single reading phase and a single message from the Master reader to the Host computer. It is not necessary to bring the External Trigger signal to all the read- ers.

In the Master/Slave Synchronized layout the Master operating mode can only be set to PackTrack or Phase Mode.

The TCP/IP and ID-NET interfaces are connected as shown in the following figures.

Figure 23 - Example ID-NET Synchronized Layout with Master on-board TCP/IP Ethernet Interface to Host

The Master reader can be connected to the CBX series connection box with the advan- tage of the Backup and Restore configuration function (CBX + BM100 module).

All devices always support multiple output channels (i.e. for data monitoring).

Verify Master/Slave Synchronized Configuration

From the Master configuration, run the application and monitor the output data from the DL.CODE Console or a configured channel terminal.

If necessary, as a troubleshooting tip, you can temporarily apply the Reading Mask field in place of each Code Content field to verify if all devices are reading. To do this:

Connect to the Master device via Ethernet and from the Data Formatting step, change each Expected Code Field Type from Code Content to Reading Mask.

Run the application and monitor the output data from the DL.CODE Console or a configured channel terminal.


Output Data


Reading Mask

The Reading Mask shows which device reads which Expected Code. The mask is com- posed of a fixed 32-character string (0=No Read or 1=Read) representing the 32 possible readers in an ID-NET network. By default the Master is the last character in the string (Master on Right) but this can be changed. The Slaves are shown adjacent to the Master in order (1 to 31), by default from right to left.

Example: Master + Slave 1 = 00000000000000000000000000000011

The figure above shows that both the Master and Slave 1 are reading Code 128 while only the Master is reading Code 39.

After verifying correct functioning of the reading devices, return the Expected Code fields from Reading Mask to Code Content.

If you haven’t made any other changes you can exit without saving. Otherwise, save the Master device configuration overwriting its previous one, making sure to save without Clone Master Configuration on Slaves, otherwise the Slave configu- rations will be overwritten.

To view the connected Slave configurations:

Click on the Internal Network View tab at the bottom of the screen
Open the Master branch by clicking on the arrow to the left of the Master icon.
Select any slave. Wait for the configuration to load.
Click The Configuration tab at the bottom of the screen.

By selecting the various configuration steps above you can visualize the slave configura- tion.

NOTE: You can modify some Slave Synchronized parameters from this view but you cannot save them here.

To save changed slave parameters, you must click on the Master and Save the configuration overwriting it, making sure to select S**ave on Slave** Device but without C**lone** Master Configuration on Slave**,** otherwise all the Slave configuration parameters will be overwritten by the Master configu- ration.

Alternative Device Role Selection

To set up a Master/Slave Internal Network Role you can also enter the Device Environ- ment settings from the Device menu>Settings>Settings and open the Internal Network Settings group.

Change the Internal Network Role to Master or Slave accordingly.

Wait for the device to reset. It may be necessary to wait several sec- onds and then perform a Discovery to refresh the device list area. You should now see the Master device with its relative icon.

Likewise, you can set the device Internal Network Role to Slave and the Reading Point Address (ID-NET address) according to the network configuration.

Complete the Slave configuration and save it to the device. Complete all the ID-NET Slaves in the same way.

The Master must be set to expect the same number of slaves as foreseen by the applica- tion. Now by simply making the electrical connections the network will be automatically recognized upon power up.

CHAPTER 11 PACKTRACK CALIBRATION

PackTrack Calibration can be performed on all Standalone or Master Matrix N family readers that support this feature.

OVERVIEW

PackTrack Operating Mode is a method used to correctly assign codes read to their cor- responding parcel or pack in systems where multiple packs are simultaneously present in the reading area.

The figure below illustrates the main concepts defining a PackTrack system. The main hardware parts are: conveyor, Matrix N reader(s), encoder (tach), and presence sensor (photocell).

The Reading Area corresponds to the Field Of View of the Matrix N reader.

An area called the Tracking Area is defined between the System Reference Point and the Transmission Line (Tx Line) and obviously includes the Reading Area. All packs passing through the system will have their position tracked.

The System Reference Point is defined as the point where the coordinates (X, Y, Z = 0). The Presence Sensor is normally aligned at the Y = 0 coordinate. If necessary, (after first- time calibration), it can be offset using the PS Line parameter.

The Encoder signal (Encoder Step), together with the Presence sensor is used to track the length of the pack as it passes through the system. The physical encoder can be replaced by an internal signal representing a constant speed conveyor, depending on the application.

When the pack transits the Tx Line its message is sent to the Host.

CALIBRATION PATTERN

Top/Bottom Orientation

The Calibration Pattern has a precise orientation as shown in the image. The top has 4 black squares and the bottom has 3 black squares.

During the calibration process the user has to input the coordinates measured from the System Reference Point to the lower left corner of the Calibration Pattern indicated by the red circle.

Left/Right Orientation

When calibrating left/right side readers, the Calibration Pattern is aligned to match the Y-axis (rotated 90° or 270°). This means the short side of the pattern is now aligned with the Z-axis.

Top/Bottom Calibration Chart Positioning

Right Side Calibration Chart Positioning

For Right side readers, the pattern should be placed as shown below so that measure- ments can easily be taken from the pack itself. The Conveyor Direction Arrow must always be aligned with the conveyor direction.

Calibration Pattern

Measurement Reference Point

Left Side Calibration Chart Positioning

For Left side readers, the pattern should be placed as shown below so that measure- ments can easily be taken from the pack itself. The Conveyor Direction Arrow must always be aligned with the conveyor direction.

Calibration Pattern

Measurement Reference Point

REFERENCE SYSTEM

The image below shows the coordinate reference system on the conveyor: the origin of the coordinate reference system is the System Reference Point.

The Y-axis runs parallel to the conveyor movement direction. So the Y coordinate of a point is measured as the distance between that point the and the System Reference Point along the conveyor direction.

The X-axis runs perpendicular to the conveyor movement direction. The X coordinate is measured as the distance between the point and the System Reference Point across the conveyor.

The Z-axis runs vertically through the conveyor plane with the positive direction above the conveyor.

REQUIREMENTS

The following is a list of required hardware/software that supports PackTrack for Matrix and is necessary for performing the PackTrack Calibration.

• DL.CODE release: 1.00 or later

• Matrix N Standard Application Program Software: 1.00

• or later

• Products: Matrix 300N™ Matrix 410N™, Matrix 450N™, XRF410N™1

• PackTrack Calibration Pattern

CAUTION: Print either the A4 or Letter size pdf file according to the paper size you are using. Printing on the wrong size paper or rescaling the Cali- bration Pattern will cause PackTrack calibration errors.

• Tape Measure

• These instructions

TOP CALIBRATION USING DL.CODE

CAUTION: The conveyor must be STOPPED while performing this procedure!

NOTE: Standard Setup including optical Calibration must be completed before performing PackTrack Calibration.

Calibration is performed using the Calibration Pattern positioned on the plane corre- sponding to the tallest pack, (Near Plane, i.e. closest to the Matrix reader) and on the plane corresponding to the shortest pack, (Far Plane, i.e. farthest from the Matrix reader).

The PackTrack Calibration is completed only after both planes have been calibrated and saved in Flash.

NOTE: Once a completed calibration is performed, it is not possible to per- form calibration on a single plane, for example modifying one plane while maintaining the previous parameters of the other plane. The PackTrack Calibration always requires both steps to be completed.

For XRF410N products, PackTrack Calibration must be performed separately for all the read- ers, first the Master and then the Slave (or Slaves in the case of Extended models).

STEP 1 - Run PackTrack Calibration:

Select PackTrack Calibration from the toolbar icon or item in the DL.CODE Task Area.

Set the Device Position to Top from the dropdown list.

Click on the Calibrate button to open the Calibration Planes panel for co-ordinate input.

STEP 2 - Determine the PackTrack System Reference Point:

Determine the PackTrack System Reference Point, if possible on the conveyor frame surface, where the X, Y, Z co-ordinates = (0,0,0). Visibly mark this point on a piece of tape or other surface, so that it can be used to make the measurements necessary for calibration. The Y = 0 value normally corresponds to the PS Line position.

STEP 3 - Far Plane Calibration:

NOTE: Step 3 and Step 4 can be inverted.

The reader should already be running (illuminator flashing and acquiring images) so that positioning can be seen on the monitor. The pause button should be shown indicating the reader is running.
Place the Calibration Pattern so that it is completely visible in the monitor window and it corresponds to the plane representing the lowest pack allowed to pass through the system on the conveyor. This is the Far Plane which can also be on the conveyor surface.

NOTE: The Calibration Pattern must be aligned so that the y-axis is parallel to the conveyor movement direction**.**

Press the Pause button.
Using the tape measurement, physically measure the X, Y and Z offsets from the System Reference Point to the lower left corner of the Calibration Pattern and input this data (mm) into the Far Plane Calibration boxes.
Press the Calibrate Far button for start Far Calibration.
Wait until the operation finishes. An orange progression bar runs above the Cali- brate Far button and should end in a solid green bar indicating successful calibra- tion of the far plane.

Possible error causes:

• Calibration Pattern is not completely contained in the Field of View.

• Calibration Pattern is partially obscured by objects covering it.

STEP 4 - Near Plane Calibration:

NOTE: Step 3 and Step 4 can be inverted.

Press the Play button. The reader begins to acquire images again.
Place the Calibration Pattern on a pack so that it is completely visible in the moni- tor window and it corresponds to the plane representing the tallest pack allowed to pass through the system on the conveyor. This is the Near Plane.

NOTE: The Calibration Pattern must be aligned so that the y-axis is parallel to the conveyor movement direction**.**

Press the Pause button.

Using the tape measure, physically measure the X, Y and Z offsets from the System Reference Point to the lower left corner of the pack (aligned with the Calibration Pattern) and input this data (mm) into the Near Plane Calibration boxes.
Press the Start button for Near Calibration.

Wait until the operation finishes. An orange progression bar runs above the Cali- brate Near button and should end in a solid green bar indicating successful cali- bration of the near plane.

Possible Error Causes:

• Calibration Pattern is not completely contained in the Field of View.

• Calibration Pattern is partially obscured by objects covering it.

In this case (first time calibration), it is possible to repeat the Near Calibration without losing the previously completed Far Calibration.

NOTE: The items in the monitor window are still shown as “Not Calibrated” because the calibration has not been saved yet.

STEP 5 - Saving Calibration:

Click on the Apply button to save the calibration values in the reader flash mem- ory.

The calibration also advises the minimum distance between packs (Min Pack Distance), for which correct code to pack assignment can be guaranteed.

At this point, PackTrack Calibration has been successfully completed.

STEP 6 - Verify Calibration Results:

Place a pack, code or other object onto either the Near or Far plane at a different coordinate from the calibration, however it must be visible in the monitor win- dow.

Click on the Show Real World Coordinates icon. A green cross will appear in the monitor window. Drag this cross with the mouse to an easy-to-measure reference point (i.e. pack edge).

Using the tape measure, physically measure the X and Y coordinates from the Sys- tem Reference Point and compare them to the data shown in the monitor window for the reference plane you are measuring.

CHAPTER 12 DPM

DPM AUTOLEARN

In DL.CODE 1.5.0 the DPM Autolearn feature has been replaced by the Automatic Setup, see “Automatic Setup Configuration” on page 20.

If you load devices with software application programs having previous versions and you don’t want to upgrade, then you will need to consult the specific software version documentation for the DPM Autolearn feature.

PRE-CONFIGURATION

Before performing Automatic Setup the following factors require attention in order to produce the best decoding results for DPM code reading applications.

The best reading results occur in static applications (no code movement during image acquisition).

When using internal illumination, reduce skew angle to minimum to allow uniform lighting on the code surface.
The code should be placed as close as possible to the center of the FoV.
Reduce reading distance to reduce ambient lighting interference.
The best internal illumination chain combination in part depends on the reading distance. More light is applied to the surface at closer distances.

CHAPTER 13 CODE GRADING

SYMBOL VERIFICATION VERSUS CODE GRADING

Symbol Verification involves completely testing the adherence of 2D and 1D codes to the parameters defined in specific International Standards in order to guarantee their reliability and therefore ability to be correctly decoded. In Symbol Verification the (Overall) Symbol Grade is only meaningful if it is expressed in conjunction with the mea- surement wavelength and aperture used. It should be shown in the format:

Grade / Aperture / Wavelength [ / Angle ] Where:

“Grade” is the overall symbol grade (i.e. the arithmetic mean of the individual Scan Grades for a number of tested images of the symbol).

“Aperture” is the aperture reference number or the diameter in thousandths of an inch (to the nearest thousandth) of the synthetized aperture.

“Wavelength” is the peak light wavelength in nanometers.

“Angle” is the angle of incidence of the illumination relative to the plane of the symbol of the illumination (if 45° it is omitted).

Code Grading for the Matrix N family reader is a feature used to evaluate the quality of a code within a specific application based only on the Scan Grade parameters defined in certain International Standards. It does not take into consideration the external envi- ronmental lighting parameters such as Aperture, Wavelength and Illumination Angle which can in any case affect the Scan Grade.

The Overall Code Grade is determined by the lowest resulting Scan Grade within the evaluated set of individual Scan Grade parameters.

Through DL.CODE you can also configure the Matrix N reader to perform Code Grading on a specific sub-set of parameters for evaluation. For example, it may be that you are only interested in grading the Print Growth and Symbol Contrast parameters as a func- tion of symbol print quality and therefore only want to monitor these two parameters. Only these two parameters then will contribute to the Overall Code Grade. See also “Code Grading Example Using ISO/IEC 16022 and ISO/IEC 18004 Standards” on page 200.

NOTE: Overall Code Grading cannot be equated with and should not be con- fused with Symbol Verification.

NOTE: Please note that whenever Image Filters are applied to the image (i.e. they are active in the device configuration currently in use), using Grading functions for Code Quality check may give unpredictable and invalid results due to non-conformance of the acquired image process to the ISO guidelines for barcodes grading.

CODE QUALITY INDEX

This grade refers to the Code Quality Standard parameter selection. Selects the Grade level that the code must meet or exceed in order to be decoded, in particular:

• if you select grade A, only codes that meet grade A will be considered Good Read, while codes that meet grade B, C, or D will be considered No Read;

• if you select grade B, only codes that meet grade A and B will be considered Good Read, while codes that meet grade C or D will be considered No Read;

• if you select grade C, only codes that meet grade A, B, and C will be considered Good Read, while codes that meet grade D will be considered No Read;

• if you select grade D, codes will be considered Good Read irrespective of their grade classification.

INTERNATIONAL STANDARDS APPLIED TO CODE GRADING

Matrix N family readers can be used to evaluate printed or marked symbols according to the ISO/IEC 16022, 18004, AIM DPM, and ISO/IEC 15416 standards.

ISO-IEC 16022

(Data Matrix - International Symbology Specification)

The ISO-IEC 16022 Standard specifies general requirements (data character encoding, error correction rules, decoding algorithm, etc.) for Data Matrix symbology.

ISO-IEC 18004

(QR Code - International Symbology Specification)

The ISO-IEC 18004 Standard specifies general requirements (data character encoding, error correction rules, decoding algorithm, etc.) for QR Code symbology.

ISO-IEC TR 29158 (AIM DPM 2006)

(Direct Part Mark Quality Guideline)

The AIM DPM Quality Guideline is applicable to the symbol quality assessment of direct parts marking performed in using two-dimensional bar code symbols. It defines modifi- cations to the measurement and grading of several symbol quality parameters.

The marking processes covered by this guideline are as follows: Dot Peening, Ink Jet, Laser Etching and Electro-Chemical Etching.

ISO-IEC 15415

(Two-Dimensional Symbols - Print Quality Test Specification)

The ISO-IEC 15415 Standard specifies the methodologies for the measurement of spe- cific attributes of two-dimensional bar code symbols, and methods for evaluating and grading these measurements and deriving an overall assessment of symbol quality.

ISO-IEC 15416

(Linear Symbols - Print Quality Test Specification)

The ISO-IEC 15416 Standard specifies the methodologies for the measurement of spe- cific attributes of linear bar code symbols, and methods for evaluating and grading these measurements and deriving an overall assessment of symbol quality.

PARAMETERS OVERVIEW

Standards Parameters	ISO/IEC 16022	ISO/IEC 18004	ISO/IEC TR 29158	ISO/IEC 15415	ISO/IEC 15416
Data Matrix	QR	2D DPM	2D	1D
Print Growth	P	P	Non Graded	P	Non Graded
Axial Non Uniformity	P	P	P	P
Unused Error Correction	P	P	P	P
Symbol Contrast
Cell Contrast	P	P	P	P	P
Cell Modulation			P	P	P
Decode			P	P	P
Fixed Pattern Damage			P	P
Grid Non Uniformity			P	P
Minimum Reflectance			P		P
Minimum Edge Contrast					P
Decodability					P
Modulation
Defects					P
Reflectance Margin					P

You can enable Code Grading by selecting the International Code Quality (CQ) Standard from the Manual Setup General Settings menu.

Set the Processing Mode parameter to Standard – Code Grading.

Select the 1D or 2D Code Quality Standard from the drop down lists: 1D: None, ISO/IEC 15416

2D: None, ISO/IEC 16022 / 18004, ISO/IEC 29158 (AIM DPM), ISO/IEC 15415

PARAMETERS OVERVIEW

Depending on the selection, the relative Overall Code Quality Settings box is displayed that allows you to select which parameters to use to determine the overall grading.

ISO/IEC 16022 AND ISO/EIC 18004 STANDARDS

The ISO-IEC 16022 and ISO-IEC 18004 Standards specify the methodologies for the mea- surement of specific attributes respectively for Data Matrix and QR code symbols, and methods for evaluating and grading these measurements and deriving an overall assess- ment of symbol quality.

Each quality parameter shall be measured and a grade on a descending scale of integers from 4 to 0 shall be allocated to it. The grade 4 represents the highest quality, while the grade 0 represents failure.

Code Quality Scan Grade Parameters

The following scan grade parameters can be evaluated for the ISO-IEC 16022 and ISO- IEC 18004 Standards:

Print Growth

Measures the deviation of actual element dimension from the expected element dimension due to the printing problems (i.e. overprint or underprint).

Underprinting Overprinting

Axial Non-Uniformity (ANU)

Measures and grades the squareness of all modules in the direction of each of the sym- bol’s major axes (X-axis and Y-axis) by applying the decode algorithm to the binarized image.

Unused Error Correction (UEC)

This parameter tests and grade the extent to which regional or spot damage in the sym- bol has eroded the information redundancy margin that error correction provides. 100% Unused Error Correction Capacity is the ideal condition.

Symbol Contrast (SC)

ISO/IEC 16022 AND ISO/EIC 18004 STANDARDS

Symbol Contrast tests that the two reflective states in the symbol, namely Light and Dark, are sufficiently distinct within the symbol.

The Overall Code Grade is determined by the lowest resulting Scan Grade within the evaluated set of individual Scan Grade parameters.

ISO/IEC TR 29158 (AIM DPM 2006) QUALITY GUIDELINE

The marking processes covered by this guideline are as follows: Dot Peening, Ink Jet, Laser Etching and Electro-Chemical Etching.

Code Quality Scan Grade Parameters

The following scan grade parameters can be evaluated for the AIM DPM Standard:

Axial Non-Uniformity (ANU)

Measures and grades the squareness of all modules in the direction of each of the sym- bol’s major axes (X-axis and Y-axis) by applying the decode algorithm to the binarized image.

Cell Contrast (CC)

Measures and grades the difference between the means of brightest and darkest values of the symbol (instead of determining differences between the brightest and darkest values).

Cell Modulation (CM)

Cell modulation analyzes the grid center points within the data region to determine the reflectance uniformity of light and dark elements after considering the amount of error correction available in the code.

Decode

ISO/IEC TR 29158 (AIM DPM 2006) QUALITY GUIDELINE

The Decode parameter tests, on a Pass/Fail basis, whether the symbol has all its features sufficiently correct to be readable. If the image cannot be decoded using the symbology reference decode algorithm, then it shall receive the failing grade 0. Otherwise, it shall receive the grade 4.

This parameter then will always produce Grade A for good reads. If the code cannot be decoded, then a No Read result will be produced by the reader so you will never have a Grade F result for this parameter.

Fixed Pattern Damage (FPD)

This metric is similar to Cell Modulation, but it analyzes the finder pattern and clock pat- tern as well as the quiet zone around the code instead of the data region.

Grid Non-Uniformity (GNU)

Measures and grades the largest vector deviation of the grid intersections, determined by the reference decode algorithm from the binarized image of a given symbol, from their “ideal” theoretical position. Assuming a grid on which the ideal angle of intersec- tion is 90°, any angle deviation from 90° constitutes Grid Non-Uniformity.

Minimum Reflectance (MR)

The image brightness is adjusted on a reference part, after which this calibrated value is compared with the reflectance of that part. Minimum Reflectance is the ratio of the parts reflectance to the calibrated reflectance

Unused Error Correction (UEC)

This parameter tests and grade the extent to which regional or spot damage in the sym- bol has eroded the information redundancy margin that error correction provides.

100% Unused Error Correction Capacity is the ideal condition.

Non Graded Parameters

Print Growth

Measures the deviation of actual elements dimension from the expected element dimension due to printing problems (i.e. overprint or underprint).

Underprinting Overprinting

ISO/IEC 15415 STANDARD

The ISO-IEC 15415 Standard specifies the methodologies for the measurement of spe- cific attributes two-dimensional bar code symbols, and methods for evaluating and grading these measurements and deriving an overall assessment of symbol quality.

Code Quality Scan Grade Parameters

The following scan grade parameters can be evaluated for the ISO-IEC 15415 Standard:

Print Growth

Measures the deviation of actual elements dimension from the expected element dimension due to printing problems (i.e. overprint or underprint).

Underprinting Overprinting

Axial Non-Uniformity (ANU)

Measures and grades the squareness of all modules in the direction of each of the sym- bol’s major axes (X-axis and Y-axis) by applying the decode algorithm to the binarized image.

Unused Error Correction (UEC)

Symbol Contrast (SC)

Symbol Contrast tests that the two reflective states in the symbol, namely Light and Dark, are sufficiently distinct within the symbol.

Decode

Fixed Pattern Damage (FPD)

This metric is similar to Cell Modulation, but it analyzes the finder pattern and clock pat- tern as well as the quiet zone around the code instead of the data region.

Grid Non-Uniformity (GNU)

Modulation (MOD)

Modulation is the ratio of the minimum edge contrast to Symbol Contrast. It can be con- sidered as the quality of the Analog signal related to the printing contrast.

The Overall Code Grade is determined by the lowest resulting Scan Grade within the evaluated set of individual Scan Grade parameters.

ISO/IEC 15416 1D STANDARD

The ISO/IEC 15416 Standard specifies the methodologies for the measurement of spe- cific attributes of linear bar code symbols, and methods for evaluating and grading these measurements and deriving an overall assessment of symbol quality.

Bar code symbol quality assessment shall be based on an analysis of the Scan Reflec- tance profiles. The scan reflectance profile is a record of the Reflectance values mea- sured on a single line across the entire width of the barcode.

Figure 24 - Scan Reflectance Profile

Symbol Quality grading shall be used to derive a relative measure of symbol quality under the measurement conditions used. Each scan reflectance profile shall be analyzed and a grade on a descending scale of decimals from 4.0 to 0.0 shall be allocated to each of the parameters evaluated.

Code Quality Scan Grade Parameters

The following scan grade parameters can be evaluated for the ISO-IEC 15416 Standard:

Decode

The symbology reference decode algorithm shall be used to decode the symbol using the element edges determined on the Scan Reflectance profile. This algorithm may be found in the symbology specification.

Decodability

The decodability of a bar code symbol is a measure of the accuracy of its production in relation to the appropriate reference decode algorithm.

Defects

Defects are irregularities found within elements and quiet zones, and are measured in terms of element reflectance non-uniformity.

Element reflectance non-uniformity within an individual element or quiet zone is the difference between the reflectance of the highest peak and the reflectance of the low- est valley.

Defect measurement is expressed as the ratio of the maximum element Reflectance Non-Uniformity (ERNmax) to Symbol Contrast.

Minimum Edge Contrast (EC)

Edge contrast is the difference between the Rs (Space Reflectance) and Rb (Bar Reflec- tance) of adjoining elements including quiet zones.

The lowest value of edge contrast found in the scan reflectance profile is the minimum edge contrast, ECmin.

Minimum Reflectance (Rmin)

Rmin is the lowest reflectance value in the scan reflectance profile. Rmin shall not be higher than 0.5 x Rmax. This parameter is intended to ensure that Rmin shall not be too high, especially when the value of Rmax is high.

Modulation (MOD)

Modulation is the ratio of the minimum edge contrast to Symbol Contrast. It can be con- sidered as the quality of the Analog signal related to the printing contrast.

Symbol Contrast (SC)

Symbol contrast is the difference between the highest and lowest reflectance values in a scan reflectance profile.

Reflectance Margin

Reflectance margin measures how close the reflectance value of the darkest space or palest bar is to the global threshold, expressed in terms of the symbol contrast. When this value is less than 5% it is likely that the barcode is close to failing on decode.

NOTE: To successfully perform Code Grading according to ISO/IEC 15416 Standard, all Scan Grade parameters must be enabled, as shown in the fig- ure below.

The Multiple Result View shows additional information on the decoded symbologies, such as the Quiet Zone, which indicates a trend in the quiet zone quality.

CODE GRADING EXAMPLE USING ISO/IEC 16022 AND ISO/IEC 18004 STANDARDS

CODE GRADING EXAMPLE USING ISO/IEC 16022 AND ISO/IEC 18004 STANDARDS

The output message can also be defined to include the scan grade parameters.

CHAPTER 14 DEVICE CONFIGURATION SETTINGS

The Statistics behavior for the DL.CODE Monitor is managed through the Configuration Settings window.

The other configuration groups manage some special application parameters for hybrid systems where Matrix readers are used in combination with other devices and monitor- ing software.

ACCESSING DEVICE CONFIGURATION SETTINGS

To access the device configuration settings the device must be connected to DL.CODE. From the Device>Settings>Configuration Settings menu open the Configuration Settings window.

This window features the following fields:

The configuration Name and Version of the Default Configuration are reported in the first group (read-only).

This is independent from the actual configuration currently running on the connected device.

STATISTICS

This group manages the statistics reporting behavior in the Monitor Statistics page. See also “Monitoring Statistics” on page 127.

Session lets you set the number of reading phases to monitor for a Ses- sion (from 10 to 1000).

Enabled Counters lets you choose which counter fields to visualize in the Monitor Statistics page.

LEDs CONFIGURATION

This group manages the LEDs behavior of your reader.

If User-defined is selected, the Green/Red Spots and the 360° Feedback can be configured by the user.

If STS Mode is selected, the default LEDs behavior of your reader is used.

In particular, the STS Mode is default for Matrix 320 ATS readers, but it can be enabled for any product working in Phase Mode. The STS Mode behaves as follows:

• the Green/Red Spots and the 360° Feedback cannot be controlled by the user;

• when a Master or Slave reader reads a readable code, the Green Spot and the Green 360° Feedback turn on for 500 ms;

• on Good Read, Success, and Match analysis result, no feedback is provided;

• on No Read, Failure, No Match, and Multiple Read analysis result, the Red Spot and Red 360° Feedback of the Master reader turn on;

• on Partial Read analysis result, both Green and Red 360° Feedbacks of the Master reader turn on, resulting in a Yellow 360° Feedback, however the unreadable codes are not shown.

NOTE: When User-defined is selected in a cluster configuration, the Green Spot and the Green 360° Feedback behavior of the Slave devices cannot be defined by the user, but depends on code read events. In particular, the Green Spot and 360° Feedback turn on when the Slave device successfully read a code.

WEBSENTINEL CONFIGURATION

This group manages configuration to the WebSentinel PLUS Monitor- ing software program.

WebSentinel Monitor Status enables or disables connection to the WebSentinel PLUS Monitor program.

Master Diagnostics Check Period sets the polling frequency for Diagnostic messages to be reported to WebSentinel PLUS.

SC5000 CONFIGURATION

NOTE: This configuration can only be used in PackTrack operating mode and Code Combination data collection method.

This group manages the configuration of the Matrix device to the SC5000 Controller in a Hybrid configuration.

SC5000 Status enables or disables connection to the SC5000 Controller.

SC5000 IP Address must match the SC5000 Controller.

SC5000 Port must match the SC5000 Controller.

Start Position is the address number (1 to 31) of the Matrix Master or Stand Alone reader which acts as a Slave to the SC5000.

The Matrix Master reader has its own slaves (ID-NET network) whose addresses will automatically be assigned by the SC5000 in consecutive order to the Matrix Start Posi- tion address.

SC5000 Heartbeat Timeout must match the SC5000 Controller. A value of 1 to 180 sec- onds can be configured for the Heartbeat.

SC5000 Diagnostic Timeout sets the polling frequency (in seconds) for Diagnostic mes- sages to be reported to the SC5000 Controller.

NOTE: Since messages sent to the SC5000 on the selected communication channel will be formatted by the SC5000, DL.CODE message Data Format- ting for this channel is ignored. This is not graphically indicated in DL.CODE, however do not disable Message Output Channels.

If necessary, Image Saving can be applied, see "Image Saving" starting on page 136.

See the Matrix-SC5000 Hybrid System Application Note for complete setup and configu- ration.

CRISPLANT PROTOCOL CONFIGURATION

NOTE: This protocol can only be used in Phase Mode or PackTrack operating modes.

This group manages configuration for the Crisplant Protocol.

Status enables or disables Crisplant pro- tocol configuration.

Version (Type) selects the Crisplant pro- tocol type. Currently only P10 is sup- ported. The <CR><LF> characters appear at the end of transmitted/received tele- grams.

Length (Index) selects between a 4-bit or a 6-bit index applied to the beginning of the telegram. This must match the incoming Crisplant index type.

Heartbeat Timeout must match the Crisplant protocol. A value of 1 to 180 seconds can be configured for the Heartbeat. A value of 0 means Heartbeat is disabled.

Channels selects which Matrix channel the Crisplant protocol is sent over. This should be a dedicated channel whose communication parameters match the Crisplant Host channel. Matrix Channel parameters are set in the Channels branch of the Configuration Parameters tree area.

NOTE: Since messages sent to the Crisplant Host on the selected communi- cation channel will be formatted with the Crisplant Protocol, DL.CODE mes- sage Data Formatting for this channel is ignored. This is not graphically indicated in DL.CODE, however do not disable Message Output Channels. See following example.

Example: Crisplant Protocol Communication on Matrix Main Serial port

CRISPLANT PROTOCOL CONFIGURATION

For this port the messages will be sent according to the Crisplant protocol and ignore the Data Formatting applied to the TCP Server Port. Even if not used, do not disable the Matrix TCP Server Message Output Channel.

CHAPTER 15 DEVICE ENVIRONMENT SETTINGS

ACCESSING DEVICE ENVIRONMENT SETTINGS

To access the device environment settings obviously the device must be connected to DL.CODE. From the Device>Settings>Settings menu open the Device Environment Con- figuration window.

The following fields are presented:

Device Name (default “Matrix”) can be personalized by typing a new name in this field.

This can be used to distinguish this device from others in the network (i.e. a name to indicate the device position in the network).

This name also shows up in the Device List Area.

See also note below for use with embed- ded Profinet-IO communication.

Startup Configuration which can be changed by selecting a different configu- ration from the dropdown list (if any).

ACCESSING DEVICE ENVIRONMENT SETTINGS

About Device gives details about the various software components currently loaded and running on this device. This data is important to know for troubleshooting pur- poses.

NOTE: When using embedded Profinet IO Fieldbus communication, Device Name coincides with the Station Name parameter and therefore must adhere to the fol- lowing rules in order to be recognized by the Profinet Master (Host).

Station Name is a string (max 240 characters) which identifies the node on the Profinet IO network as an alternative to the IP address. The syntax is:

- one or more "labels" separated by the . (dot) character

- max label length is 63 characters

- valid characters are lower case letters (a..z), numbers (0-9) and - (dash) char- acters

- the . (dot) and - (dash) characters cannot be used as the first or last character in the name.

Example name showing four labels: device-1.machine-8.plant-**234.vendor**

If the Station Name is changed by the host application during runtime, a reset is required in order for changes to have effect.

NOTE: A possible mismatch of the device type declaration on GSDML files and device FWs could show a wrong “Device Type” label on T.I.A. environ- ments. This does not affect the correct Profinet-IO behavior.

ETHERNET SETTINGS

This group presents all the Ethernet Set- tings for correct device connection to the LAN.

It can also be accessed directly by clicking on the wrench icon in the device list area as shown in "Ethernet Device Discovery" on page 13.

Change the Ethernet Settings (IP Address, Subnet Mask, Gateway Address etc.) according to the network requirements.

The Keep Alive Timeout parameter selects the period for which a signal is sent from the device to maintain the Ethernet connection with the DL.CODE UI configuration environment.

NOTE: When using DHCP, if there is a communication loss (i.e. cable dis- connect), the reader will take about 40 seconds to boot.

NOTE: If using DHCP with the embedded Profinet IO interface, the Profinet IO Host will not be able to change the IP address. For this interface it is suggested to use Static IP addressing.

INTERNAL NETWORK SETTINGS

NOTE: All devices are pre-assigned an Internal Network Role independent from their use. If the device is not used in an ID-NET network then this set- ting can be ignored.

This group allows managing the device role in an ID-NET network (Master or Slave).

The Reading Point Address indicates the address of the slave reader. This address is set automatically through the Setup Internal Network Configuration proce- dure but it can also be set here manually (1-31 for ID-NET Slaves).

The ID-NET Baud Rate is selected here and must be common to all devices in the network.

For a Matrix Slave Reader the Master Device Type parameter can be selected between Matrix Device or SC4000 ID-NET Controller.

See the device Reference Manual for details on ID-NET network configuration.

X- PRESS CONFIGURATION

This group allows managing the HMI X-PRESS™ behaviour. See the device Ref- erence Manual for more details on the X- PRESS features.

Configuration Status enables/disables the X-PRESS features available through the multifunction key on the device.

X- PRESS Function (1-4) assigns an HMI function selected from the list to each one of the X-PRESS keys on the device.

Number of Samples selects the number of samples to analyze for the Test percent- age.

Test Timeout sets when the expired timeout causes the Test feature to exit.

Aim Timeout sets when the expired timeout causes the Aim/Autofocus feature to exit.

Saving Options selects whether the X-PRESS Setup and Learn features will save their results to Permanent or Temporary memory. If set to Permanent memory, the configu- ration will be saved as the default configuration in the job list having the Configuration Name.

Configuration Name is the name given to the configuration saved to permanent mem- ory by the X-PRESS Setup and Learn procedures.

Autolearn Timeout sets when the expired timeout causes the Learn feature to exit.

PACKTRACK CALIBRATION

This group shows the PackTrack Cali- bration parameter settings (read- only) for a device that has already been calibrated.

LED CONFIGURATION

This group manages the device LEDs and Beeper behavior.

COM LED Function selects whether the COM LED on the device (which signals activity on the Main Serial port) is ON when data is transmitted by the device (TX) or received from the Host (RX).

Beeper Status enables/disables the device beeper.

Beeper Activation Events selects which events will trigger the beeper.

Beeper Deactivation Timeout deter- mines the length of the beeper sig- nal.

LEDs Deactivation Timeout determines the length of time the LED signals are ON.

Focusing Pointer Status (for devices with laser pointers) sets the aiming system man- agement: Disabled - laser pointers always OFF; Always On - laser pointers always ON; Calibration Only - laser pointers only ON during calibration procedures.

Multiple Read Treated As determines which device LED will be activated on a Multiple Read event: Complete Read – the Good Read LED will be activated; No Read – the Sta- tus LED will be activated.

MAINTENANCE SETTINGS

Current Illuminator Model shows the internal illuminator model associated with this device.

If the device is not correctly associated with its internal illuminator incorrect func- tioning and/or damage can occur. For Matrix 410N devices see the following Illu- minator Management procedure.

PPI is the same value saved in the Acquire PPI image density setting procedure located in the Manual Setup – Image Set- tings branch. Here it can be set manually although it is advised to use the Acquire PPI procedure.

Enable BM100 Detection if enabled, at startup, the reader sends a message to recog- nize the presence of, and communicate with, the External Backup Memory (BM100 Backup Module or integrated QLM-Series accessories). If using the Backup Memory, this parameter must be enabled.

BM150 Display Layout selects which information layout to display on the BM150 acces- sory display for CBX500 connection boxes. See the Matrix N Reference Manual for more details.

DL.CODE Illuminator Management Procedure for Matrix 410N

In the DL.CODE Maintenance Settings

> Current Illuminator Model item, select the correct Illuminator being used from the dropdown list.

Click OK and at the device reset prompt click Yes and wait until the device resets. You can confirm by reopening this item from the same menu.

The above procedure must also be per- formed before any attempt to use the X-PRESS configuration on readers mounting the LT-005, LT-007, LT-010 or LT-011 illumi-

nators.

WEB MONITOR

On the Web Monitor field you can enable the web monitor function for your reader. For more information, refer to “Web Monitor” on page 84.

OPC UA SETTINGS

On the OPC UA Settings field you can enable the OPC UA protocol on your OPC UA-based Matrix reader. For more infor- mation, refer to your Product Reference Guide.

CHAPTER 16 COMPARATOR

The Comparator feature can be used to compare a configuration on an online or offline device with:

• a default configuration,

• a configuration on PC,

• a device configuration (if applicable).

ACCESSING THE COMPARATOR

The Comparator can be accessed clicking on its toolbar icon:

The Comparator can also be accessed from the Device menu, as illustrated below:

Click on the Switch to Configuration/Monitor icon to exit the Comparator.

COMPARATOR WINDOW

The Comparator view displays four panels:

1	2	3	4

• Panel 1 contains the parameter tree of the Device Configuration.

• Panel 2 is the Device Panel showing the parameters related to the element selected on panel 1.

• Panel 3 is the Reference Panel showing the parameters related to the elements selected on the reference tree (panel 4).

• Panel 4 contains the parameter tree of the Reference Configuration.

You can switch the parameters displayed in panel 1 and panel 4 through the buttons at the bottom of the window:

• Configuration.

• Configuration Settings (refer to "Device Configuration Settings" on page 202).

• Device Environment Configuration (refer to "Device Environment Settings" on page 208).

COMPARATOR

USING THE COMPARATOR

When the Comparator identifies differences between the two configurations, it will mark out those elements in purple:

In the example above, the Comparator detected one or more differences in the Datama- trix tree item of the Device Configuration compared to the Reference Configuration. Looking at the middle panels, there is one Datamatrix parameter enabled in one config- uration and disabled in the other.

The Comparator will also mark out elements that are present in only one configuration, as shown below with the Reader UDP Channel item:

An exception to this rule is when a parameter is not relevant for visibility rules. In the example below, the Image Mirroring parameter is not marked out because irrelevant, as the parameter “Both not and mirrored codes” is enabled in the device configuration.

NOTE: In the Comparator view, only adjustable parameters can be modified in the device configuration. All other settings are grayed out and can be changed after exiting the Comparator.

MAINTENANCE

As with nearly all electronic components, performance may drift over time making it necessary to calibrate the device at periodic intervals for optimal reading performance. There is a Recalibration Tool provided in DL.CODE which performs the recalibration pro- cedure. If it ever becomes necessary to perform this procedure, contact our Technical Support team for assistance.

This procedure is intended to be performed by trained technicians and not performed frequently (i.e. only after several years of operation and only if the focus level adversely affects decoding).

MAINTENANCE

UPDATE PACKAGE

The user can upgrade or downgrade the device firmware (application program, schema, etc.) to a different version.

• First connect your Matrix device (preferably via Ethernet) and select it on DL.CODE.

• In the Main Menu, select Device > Update Package.

• Select the suitable package to load on your Matrix device. The following pop-up window is displayed: click Yes to confirm and start the upgrade procedure.

• During firmware upgrade, a progress bar is displayed reminding the user NOT to turn off or unplug the device.

• The following Device Restart Information pop-up window is displayed. Click OK and wait approx. 1 minute to allow the device to restart and changes to be applied.

CAUTION: Do NOT unplug the device or attempt to reconnect the device to DL.CODE during this phase.

The procedure is completed when all LEDs on the HMI turn on and off, and only the green Ready LED remains on. Now you can reconnect the device and check that the firmware has been upgraded correctly on the Selected Device Information Area**.**

TROUBLESHOOTING

Problem	Solution
Online Device is not dis- played in the Device Selection Area	In order to be found by DL.CODE, Online devices must be powered on and connected to the Local Area Network; if you don't see the desired device within this list, please verify its connections to the LAN and assure it is powered on; then click on the Discovery icon to run a new device search.
Serial Device is not dis- played in the Device Selection Area	In order to be found by DL.CODE, Serial devices must be powered on, connected a Serial port of the configuration PC and have the serial port driver installed. if you don't see the desired device within the Serial Devices list, please verify its connections and assure it is powered on and the serial port driver is installed; then click on the Discovery icon to run a new device search.
Cannot open a device con- figurationDL.CODE Selected Device Information area shows a yellow background	Exit DL.CODE and cycle power to the device. Run DL.CODE and reselect the device. The background should now be green and device configurations can be opened.
Cannot Configure the Device (parameters and icons appear in grey)	The device is in run mode. Click on the Pause button to exit run mode.
Connection problem between DL.CODE and Online Device	If more than one LAN card is present on the local PC and a Simulator (offline device) is enabled in DL.CODE (disabled by default), the program can freeze up. Either disable the simu- lators in DL.CODE or disable the other LAN cards on the PC.
The User is not able to download images	The FTP Username and FTP Password must be the same as the ones defined in the FTP Client.

TROUBLESHOOTING

Problem	Solution
Some Images are missing	Image availability depends heavily on the number of images transferred and the rate of transfer, (system throughput and network bandwidth). Since Image downloading is usually based on specific criteria (i.e. No Read or Multiple Read con- ditions) the FTP Server is adequate to handle most applica- tions.In extreme cases where a high throughput application requires all images to be downloaded it is possible that some images may not be available on the reader having been over- written in the device's circular buffer.
The phase duration is dif- ferent from that expected.	Phases lasting more than 1 minute are not guaranteed and may cause malfunctions.We suggest setting a Phase Off Timeout up to 1 minute.

Problem

Solution

Some Images are missing

Image availability depends heavily on the number of images transferred and the rate of transfer, (system throughput and network bandwidth). Since Image downloading is usually based on specific criteria (i.e. No Read or Multiple Read con- ditions) the FTP Server is adequate to handle most applica- tions.In extreme cases where a high throughput application requires all images to be downloaded it is possible that some images may not be available on the reader having been over- written in the device's circular buffer.

The phase duration is dif- ferent from that expected.

Phases lasting more than 1 minute are not guaranteed and may cause malfunctions.We suggest setting a Phase Off Timeout up to 1 minute.

APPENDIX A

TCP/UDP PORTS

The following table lists the local ports reserved for TCP/UDP channels.

NOTE: To avoid malfunctions, do not use these ports for other services or applications.

TCP	23
80
1023
4321
12345
23456
40000
54147
UDP	4088

APPENDIX B

WEBSENTINEL PLUS INVESTIGATOR

OVERVIEW

WebSentinel PLUS Investigator is a software add-on to Datalogic’s WebSentinel PLUS tool. It provides no read classification and bar code grading for each barcode read during normal operations. No Read classification is an important feature. By post pro- cessing saved images of No Reads, WebSentinel PLUS Investigator sorts these items into categories and helps you determine No Read root causes. Bar code grading is another important feature that helps estimate trends in printing quality and determines decreasing quality before labels can become no reads.

For more information, refer to the WebSentinel PLUS Investigator Installation and Con- figuration Guide.

CONNECTING MATRIX USING DL.CODE

CAUTION: So that WebSentinel Investigator can successfully receive coherent information from imagers, you must set each imager within the same scanpoint to use the same Barcode Table.

The main steps to enable WebSentinelPLUS for your Matrix reader:

• Start the DL.CODE setup software.

• Enable WebSentinelPLUS.

• Add FTP Client as a communication channel.

• Set Image Saving.

DL.CODE Settings

Start DL.CODE, and access the configuration parameters for the device you wish to communicate with WebSentinelPLUS.
Click Device > Settings > Configuration Settings. The following window opens.
Set WebSentinel Monitor Status to Enabled.

When WebSentinel is enabled an Enable Extended Parcel Message parameter becomes available.

Click the drop-down to select ADP-Investigator.
Click OK to save your settings.
Click 3 Data Formatting.

WEBSENTINEL PLUS INVESTIGATOR

Under Channels, select Reader FTP Client.
Make sure the Server Address matches the WebSentinel FTP Server address.
Enter the correct WebSentinel FTP Server Remote Address and Port.
Enter the Username: ftpuser / Password: asiroot
Click Images Saving.

Set Send Image On to Analysis Complete.
Set Send Image From to Reader FTP Client.
Enter the name of the Remote Folder on the FTP Server to which the image files must be saved.

NOTE: Enter the name of the sub-folder of the home image directory set in the FTP server. For example, in the image above the M320 sub-folder has been indicated as M320. If no sub-folder is necessary, leave this parameter blank.

WebSentinel PLUS Settings

In order to read images from the ftp folder, you must edit the scan point in WebSentinel PLUS.

Set the Image Server of the Matrix reader as follows:

Select Local Settings from the WebSentinel PLUS menu.
Click on Scan Point Management, the following window opens.

Select a Scan Point and click the pencil icon to edit it, or click + in the upper left corner to add a new one.
Click on the Image Server Configuration tab.
Click on the Add image server button.
The HTTP server should be set as the images server, click on Type drop-down and select HTTP.
Enter the server IP address, the port as 80 and the path /images/<subfolder>.
Click on the Add image server button again.
Click on Type drop-down and select Local.

Enter the COMPLETE path of the local server where images from the Matrix reader will be saved.

Click Update to save the changes, click Reset to return to the fields to the previ- ously saved values, or click Cancel to return the Scan Point Management window.

© 2016-2025 Datalogic S.p.A. and /or its affiliates • All rights reserved • Without limiting the rights under copyright, no part of this documentation may be repro- duced, stored in or introduced into a retrieval system, or transmitted in any form or by any means, or for any purpose, without the express written permission of Data- logic S.p.A. and/or its affiliates • Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S. and the E.U.

*www.dat**alogic.com*

Datalogic S.r.l.

Via S. Vitalino, 13 | 40012 Calderara di Reno | Bologna - Italy Tel. +39 051 3147011 | Fax +39 051 3147205

801000230 (Rev G) September 2025

PREFACE ABOUT THIS MANUAL

Manual Conventions

TECHNICAL SUPPORT

Support Through the Website

Reseller Technical Support

CHAPTER 1

*INTRODUCTION*

MAIN FEATURES

CONFIGURATION AND MONITORING SESSIONS

SIMULATORS

DEVICE CONFIGURATION

*CHAPTER* *2*

*INSTALLATION*

DL.CODE DISTRIBUTION CONTENTS

HARDWARE REQUIREMENTS

SOFTWARE REQUIREMENTS

INSTALLING DL.CODE

Standard Installation

Silent Installation

UNINSTALLING DL.CODE

第3章 快速入门

登录

Login and Signup

Offline Login

15- day Trial

以太网设备发现

串口设备发现

DECODING CONFIGURATION PARAMETERS

Automatic Setup

Manual Setup

Automatic Setup Configuration

Error during Automatic Setup

Advanced Options

Manual Setup Configuration

OPERATING MODE CONFIGURATION PARAMETERS

Reading Phase

Good Read Setup

OUTPUT CONFIGURATION PARAMETERS

Data Formatting

Output Setup

*CHAPTER* *4*

*DL.CODE* *USER* *INTERFACE*

DL.CODE DEVICE DISCOVERY WINDOW

Device List Area

Online Device Sorting

Wink and Web Monitor icons

Control/Help Panel

DL.CODE MAIN MENU AND TOOLBAR

User Levels

MULTI IMAGE ACQUISITION SETTINGS

Automatic Image Settings Selection

External Image Settings Selection

IMAGE CROPPING

CODE AUTOLEARN FEATURE

IMAGE FILTERING

DPM Algorithms

Image Filters

Image Filter

Image Filter Setting Examples

Example 1

Example 2

MATRIX CONTROL BY FIELDBUS CHANNEL

Fieldbus Input/Output Representation in DL.CODE

Digital IO Conditioning

Fieldbus Reading Phase Control

Fieldbus Digital Output Control

Digital Input Echo to Fieldbus

TEST MODE

BACKUP AND RESTORE THROUGH DL.CODE

Backup

Restore

Replacement

RESTORE DEFAULTS

Restore Default Startup Configuration

Restore Default Environment

Restore Factory Defaults

Software Reset

WEB MONITOR

*CHAPTER* *5*

*DATA* *COLLECTION* *METHODS*

INTRODUCTION

CHAPTER 2

INSTALLATION

第3章快速入门

CHAPTER 4

DL.CODE USER INTERFACE

CHAPTER 5

DATA COLLECTION METHODS

CHAPTER 7

MESSAGE FORMATTING

CHAPTER 8

MONITOR

CHAPTER 9

IMAGE SAVING

CHAPTER 10

MULTI DEVICE CONFIGURATION OPTIONS
